Ilsco AK-6-B Aluminum Split Bolt, Main Range 6-10, Tap Range 6-10, Tin Plated, UL, CSA, Bag of 1
Ilsco AK-6-B Aluminum Split Bolt, Main Range 6-10, Tap Range 6-10, Tin Plated, UL, CSA, Bag of 1
- MPN: AK-6-B
- PPN: ILC-AK-6-B
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$23.61/ EA
Specifications
Voltage
- Voltage Rating
- 35 kV
Dimensions
- Drive Size Main
- 9/16, 3/4
- Height BX (IN)
- 2.75
- Width BX (IN)
- 6
Drive Type MainExternal Hex
Weight BX (LB)1.222
Testing Standards
- CSA File Number
- 72632
- Prop65 Compliance
- This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- UL / CULUS Specification
- UL 486A/B Listed
CSA StandardC22.2 No. 188, C22.2 No. 65
UL Control Number670B
UL File NumberE6207
Additional Class Attributes
- Connection
- Mechanical
- Number of Poles
- 1
Number of Conductors1
Material and Finish
- Conductor Material
- Copper, Aluminum
- Material
- Aluminum
Connector FinishTin
Conductor Ranges
- Conductor Range AL Solid (Secondary, tap, load)
- 6 Sol - 10 Sol
- Conductor Range AL Stranded (Secondary, tap, load)
- 6 Str - 10 Str
- Conductor Range CU Solid (Secondary, tap, load)
- 6 Sol - 10 Sol
- Conductor Range CU Stranded (Secondary, tap, load)
- 6 Str - 10 Str
Conductor Range AL Stranded (Primary, run, main, line)6 Str - 10 Str
Conductor Range CU Solid (Primary, run, main, line)6 Sol - 10 Sol
Conductor Range CU Stranded (Primary, run, main, line)6 Str - 10 Str
Conductor Range AL Solid (Primary, run, main, line)6 Sol - 10 Sol
Additional Technical Specifications
- Conductor Type
- Solid, Stranded
General
- Bag Quantity
- 1
- Direct Burial
- No
- NEMA Code
- S-588-4
Carton Quantity DescriptionSTD PACK QTY 25
Dual RatedYes
UPC Code78366900899
Specifications
- Weight
- 0.039 lbs
Bolt and Screw Sizes
- Number of Wire Binding Screws per Port
- 1
Wire Binding Torque165
Color
- Color
- Silver
Environment and Temperature
- Temperature Rating
- 90°C
