Schneider Electric ZB5AZ902 Harmony XB5 22mm Anti-Rotation Plate, Set of 10
- MPN: ZB5AZ902
- PPN: SCH-ZB5AZ902
CAD
$1.43
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This Harmony XB5, anti-rotation plate enables a more stable installation of Harmony XB5 and XB7 selector switches and emergency stop push-button heads. This mounting accessory is recommended for every installation where perfect horizontal alignment of buttons labels is required.
Features
- Specifically engineered for the Harmony XB5 series, this anti-rotation plate locks into the panel cutout to mechanically stop the operator head from spinning or shifting under repeated physical use. It eliminates the frequent maintenance headache of loose, misaligned control buttons, ensuring your emergency stops, selectors, and pushbuttons remain perfectly oriented and responsive in high-vibration manufacturing environments.
- This mounting tool provides a precise, non-slip mechanical grip around the plastic bezel locking nut, allowing panel builders to apply exact torque without marring or stripping the components. By replacing clumsy pliers or standard wrenches, it slashes assembly times across large-scale control cabinet builds while preventing expensive physical damage to the front-of-panel aesthetics.
- Molded from Schneider's high-grade, chemical-resistant plastic compound, this accessory withstands heavy exposure to industrial oils, cleaning solvents, and moisture. It will not rust, scale, or degrade over time, making it the ideal code-compliant choice for food processing facilities, wastewater treatment plants, and marine environments where metallic accessories frequently fail.
- Built to the exact mechanical specifications of the global Harmony XB5 22mm modular line, this hardware ensures a seamless, flush fit across all matching pushbuttons, pilot lights, and selector switches. This standardized architecture removes comparison guesswork from your procurement process, allowing facility electricians to stock a single, versatile accessory for all routine control station retrofits.
