APC SMT2200US Smart-UPS 2200VA Line Interactive Tower 120V, 8x NEMA 5-15R, Pure Sine Wave Output
- MPN: SMT2200US
- UPC: 731304305620
- PPN: APC-SMT2200US
CAD
$2858.21
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Smart-UPS 2200VA Line Interactive Tower 120V, 8x NEMA 5-15R, Pure Sine Wave Output
Features
- StruxureWare Data Center Expert compatible — Enables centralized management via StruxureWare Data Center Expert.
- Reduces utility costs, generates less heat. — Reduces utility costs, generates less heat.
- Green mode — Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- Energy meter — Provides actual kilowatt hours of usage for energy conscious users.
- Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning. — Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
- Intuitive LCD interface — Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
- Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding. — Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
- Pure sine wave output on battery — Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Sequenced network shutdown and reboot — Customize network shutdown and reboot sequence of connected servers and UPSs.
- Cold-start capable — Provides temporary battery power when the utility power is out.
- SmartSlot — Customize UPS capabilities with management cards.
- Temperature-compensated battery charging — Prolongs battery life by regulating the charge voltage according to battery temperature.
Documentation & Downloads
Specifications
Additional
- Output Power Capacity
- 1920 VA
- Input Voltage
- 120 V
- Topology
- Line Interactive
- Surge Energy Rating
- 530 J
- Recharge Time
- 3 h
- Output Connections
- 8 NEMA 5-15R, 2 NEMA 5-20R
- Weight
- 112.24 lb (50.91 kg)
- Mounting Location
- Front
- Reach
- Contains Substances of Very High Concern
- RoHS Compliance
- Compliant with Exemptions
- Country of Origin
- United States
Output Power1920 W
Nominal Output Voltage120 V
Waveform TypeSine Wave
Battery TypeLead-Acid battery
Input Connection TypeNEMA 5-20P
Dimensions (HxWxD)17.01 in x 7.72 in x 21.42 in (432 mm x 196 mm x 544 mm)
Cable Length6 ft (1.83 m)
Mercury FreeYes
California Proposition 65Prop 65 Compliant (contains lead)
ApprovalsCSA, TAA
ColorBlack
