Balluff BCS M30BBM2-PPCFAG-S04G Capacitive Level Sensor, M30x1.5 Thread, Ø 30 x 87 mm, IP67
- MPN: BCS M30BBM2-PPCFAG-S04G
- PPN: BAL-BCS007Y
CAD
$300.61
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
These capacitive sensors used for fill level detection detect the product, bulk material or liquids to be detected with their active surface in contact with the media. Their spherical electrical field effectively compensates for deposits on the sensing surface of the sensor.
Documentation & Downloads
Specifications
Additional
- Operating Voltage
- 10-35 VDC
- Switching Frequency
- 2 Hz
- Thread Size
- M30x1.5
- Material
- PBT, PE
- Ambient Temperature Range
- -10 to 60 0C
- Sensitivity
- media-dependent, adjustable
- Installation
- non-flush
- Additional Features
- Electrically conductive media, Foam and residue compensation
- Utilization Category
- DC -13
- MTTF
- 221 a (at 40 0C)
Rated Operating Current300 mA
Voltage Drop1.8 V max
Dimensions
8 30 x 87 mm
IP RatingIP67, IP64 at plug exit
Approval/ConformityCE, cULus, WEEE
FunctionSmart Level 15
ConnectionConnector, M12x1-Male, 4-pin
ProtectionPolarity reversal protected, Short-circuit protected, Protection against device mix-ups
Tightening Torque4 Nm
SeriesM30
