Bussmann KTK-R-2 CLASS CC FAST ACTING FUSE CLASS CC

CLASS CC FAST ACTING FUSE CLASS CC

Bussmann KTK-R-2 CLASS CC FAST ACTING FUSE CLASS CC

MPN: KTK-R-2
UPC: 051712420600
PPN: BUS-KTK-R-2

Spec sheet

In Stock

Company Stock:

00

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$15.43/ EA

Loading add to cart quantity...

Description

CLASS CC FAST ACTING FUSE CLASS CC

Features

Specifically engineered with a unique rejection tip, this Class CC fuse is designed to seat perfectly into specialized rejection-style fuse blocks, preventing the dangerous installation of lower-rated fuses. This mechanical safeguard ensures your control circuits remain protected by the exact current-limiting performance required by modern safety codes and industrial specifications.
Despite its compact 13/32" x 1-1/2" footprint, this fuse boasts a massive 200kA interrupting rating (IR) at 600V AC. This high-performance current limitation stops catastrophic fault currents in their tracks, shielding sensitive downstream components like PLC inputs, contactors, and small motors from explosive thermal and magnetic damage.
Built with a precision-engineered fast-acting element, the KTK-R-2 responds almost instantaneously to overcurrent events. This rapid clearing speed is critical for protecting specialized control transformers and electronic instrumentation where even a millisecond of excess current could result in total system failure and costly equipment replacement.
Constructed with a high-grade melamine tube and nickel-plated bronze endcaps, this fuse provides superior physical strength and exceptional thermal stability. This rugged build prevents the fuse body from cracking or charring under high-heat conditions, ensuring long-term reliability and code-compliant performance in demanding manufacturing and HVAC control panels.

Specifications

Voltage: 600 Vac

Interrupting Rating: 200 kA

Fuse Class: Class CC

Compliance: UL Listed, CSA Certified, CE, RoHS Compliant

Amperage2 A

Fuse TypeFast-acting

Dimensions1.5 in x 0.41 in

Downloads
