Telemecanique Sensors XE2SP2148 Limit switch contact block, Limit switches XC Standard, 2NC, snap action, golden surfaced
- MPN: XE2SP2148
- PPN: TES-XE2SP2148
- UNSPSC: 39121522
CAD
$122.28
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Limit switch contact block, Limit switches XC Standard, 2NC, snap action, golden surfaced
Documentation & Downloads
Specifications
Key Specifications
- Series Name
- standard format
- Range Of Product
- Telemecanique Limit switches XC Standard
- Product Or Component Type
- limit switch contact block
- Device Short Name
- XE2S
Contacts Type And Composition2 NC
Contact Operationsnap action
Associated BodyZCD69 || ZCP69 || ZCKJ || ZCKS || ZCKM
Number Of Poles2
Complementary
- Electrical Connection
- screw-clamp terminals 1 x 0.34...2 x 1.5 mm²
- Electrical Durability
- 5000000 cycles, DC-13 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13 24 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13 48 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
- Positive Opening
- with
- Contacts Insulation Form
- Zb
- Contact Code Designation
- A300 (Ue = <= 48 V), Ie = 10 mA 10 A || Q300 (Ue = >= 5 V), Ie = 1 mA
- [Uimp] Rated Impulse Withstand Voltage
- 6 kV IEC 60664 || 6 kV IEC 60947-1
[Ui] Rated Insulation Voltage300 VUL 508 || 500 V 3)IEC 60947-1 || 300 VCSA C22.2 No 14
Short-Circuit Protection10 A cartridge fuse gG
Minimum Actuation Speed0.01 mm/s
Contacts Materialsilver with gold flashed contacts
Product CompatibilityXCKJ || XCKS || XCKP || XCKD || XCKM
Maximum Resistance Across Terminals25 mOhm IEC 60255-7 category 3
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP110614EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Reach Free Of Svhc
- Yes
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationFree of Substances of Very High Concern above the threshold
