Schneider Electric TMAT2PSET Modicon M221 Connector Set, 8 Removable Terminal Blocks
- MPN: TMAT2PSET
- PPN: SCH-TMAT2PSET
CAD
$45.62
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
connector set for M2X1 - power supply This connector set is proposed as a spare part available for Modicon M221 logic controllers. It is used to connect the power supply of Modicon M221 and M221 Book controllers. It is composed of 8 removable terminal blocks with screw terminals used to equip a Modicon M221 or Modicon M221 Book logic controller. This product is certified by CE, IACS E10, CSA, RCM, LR, ABS, DNV-GL, EAC and CULus. It meets EN/IEC 61010-2-201, EN/IEC 61131-2 and EN/IEC 60664-1 standards.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Brazil, France, Indonesia |
|---|
Important Information Attributes
| Local Data Status | Publishable |
|---|---|
| Return Indicator | N |
| Stock Policy | 1 |
| Serviceability | No |
| Weee Scope | Out |
| Reach Full Compliance Status | Free of Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Free of Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant By Exemption |
| Rohs Eur Full Compliance Status | Compliant By Exemption |
| China Rohs Label | 5 |
| Without Single Use Plastic | No |
| Product Kit Identifier | N |
| Number Of Connectors | 8 terminal block |
| Product Or Component Type | terminal block |
| Sustainable Packaging | No |
| Accessory / Separate Part Destination | Modicon M221 |
| Nbr. Of Units In Pkg. | 1 |
| Take-back | No |
| Customs Code | 8536694030 |
| Local Publishable Date | 2026-01-12 |
|---|---|
| Stocking Flag | Y |
| Device Type | PLC System - PLC Component |
| Traceability | No |
| Scope Perimeter | At least in Europe |
| Reach Full Compliance Status Id | NOT_CONTAINING_SVHC |
| Rohs Eur In Scope | No |
| Rohs Eur Conformity Date | 2017 |
| China Rohs In Scope | Yes |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Electrical Connection | removable screw terminal block, 3 for connecting the AC or DC power supply pitch 5.08 mm) |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Returnability | No |
| Accessory / Separate Part Category | connection accessories |
| Accessory / Separate Part Type | screw terminal block |
| Package Weight(Lbs) | 36 g |
| Warranty (In Months) | 18 |
Environment Attributes Main
| Take Back | No |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Mercury Free | Yes |
| Packaging Made With Recycled Cardboard | Yes |
| Product Compatibility | logic controller |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Reach Free Shvc | Yes |
|---|---|
| China Rohs Regulation | X |
| Eu Rohs Directive | Compliant By Exemption |
| Packaging Without Single Use Plastic | No |
| Reach Free Of Svhc | Yes |
General Attributes
| Product Or Component Type | terminal block |
|---|
ETIM
| ETIM 8 | EC002584 |
|---|
| ETIM 9 | EC002584 |
|---|
