Schneider Electric ZA2VA11 Harmony XB5 Digital Display Body 22mm, 24V DC, IP65, Panel Mount
- MPN: ZA2VA11
- PPN: SCH-ZA2VA11
CAD
$457.86
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
This Harmony ZA2VA11 is a digital display body, decimal + BCD. It is part of the range Harmony XB5 diameter 22mm modular plastic push buttons, switches, and pilot lights.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Brazil, France
Important Information Attributes
- Persona Type Ids
- BM9, EU, LC, OM, OM8, PB, SC, SI, VR
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Current Consumption
- <= 36 mA 30 V, <= 36 mA 30 V, <= 40 mA 24 V, <= 40 mA 24 V<= 36 mA 30 V, <= 36 mA 30 V, <= 40 mA 24 V, <= 40 mA 24 V
- Electrical Shock Protection Class
- class II conforming to IEC 60536, class II conforming to NF C 20-030
- Certificate Agency
- UL, CSA
- Carbon Footprint Of The End-of-life Phase [C1 To C4]
- 0.1 kg CO2 eq., 0.0849853129
- Carbon Footprint Of The Manufacturing Phase [A1 To A3]
- 1 kg CO2 eq., 1.4645946047
- Local Data Status
- Publishable
- Return Indicator
- Y
- Stock Policy
- 2
- Weee Product Category
- 5
- Eoli Availability Display
- Yes
- Rohs Eur In Scope
- No
- Rohs Eur Conformity Date
- 1918
- China Rohs In Scope
- Yes
- With Recycled Cardboard
- No
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 1
- Function Option
- Standard
- Current State 1 Guaranteed
- 4...9.5 mA
- Mounting Support
- panel
- Product Or Component Type
- digital display body
- Range Of Product
- Harmony
- Shock Resistance
- 180 gn 11 ms IEC 60068-2-27
- Supply Voltage Limits
- 13-30 V
- Total Lifecycle Carbon Footprint
- 42 kg CO2 eq.
- Voltage State 1 Guaranteed
- 13...30 V
- Database Version
- 2022-01
- Pcr Version
- PEP-PCR-ed4-2021 09 06
- Type Of Verification For The Pep
- Independent internal review
- Functional-unit Description
- This pack comprises one wireless and batteryless pushbutton assembled on fixing collar and one receiver. Pushbutton and receiver are factory-paired. It is uses a 24V to 240V AC/DC input. The wireless and batteryless pushbutton reduces installation time and cost by eliminating wiring and associated equipment between the transmitters and the control panel. The product uses 0.72W of power when it is active and 0.6W of power when it is in standby mode for 99.86% of the time over the period of 10 years.
- Functional-unit Unit
- Unit
- Energy Consumption On Product Lifetime, In Kwh
- 84.096
- [Us] Rated Supply Voltage
- 24 V DC
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
Persona Type NamesCharge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market SegmentationCommercial, Industrial
Current State 0 Guaranteed<= 1.4 mA, <= 1.4 mA
Voltage State 0 Guaranteed-30...5 V, -30...5 V
Carbon Footprint Of The Distribution Phase [A4]0.0199042975, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]0.0169233833, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2, B3, B4, B6]41 kg CO2 eq., 40.539139038
Local Publishable Date2026-01-12
Stocking FlagY
Weee ScopeOut
Scope PerimeterAt least in Europe
End Of Life Doc RefENVEOLI2303007EN
Rohs Eur StatusCompliant By Exemption
Rohs Eur Full Compliance StatusCompliant By Exemption
China Rohs Label5
Without Single Use PlasticNo
Tier Id1
Function Option IdSTANDARD
Product Kit IdentifierN
Electronic Decodingdecimal + BCD
Product AvailabilityNon-Stock - Not normally stocked in distribution facility
Protection Typereverse polarity protection
ReturnabilityYes
Software Versionv5.9.4
Sustainable PackagingNo
Vibration Resistance10 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Pep Code"ENVPEP2303007EN"
Pep Verification Date2023-08-01
Psr VersionPSR-0005-ed2-2016 03 29
Data Sourceextrapolated product
Functional-unit Quantity1
Reference Lifetime, In Y10
Energy Model - Manufacturing [A1-a3]Energy model used: Electricity Mix; Production mix; Low voltage; UE-27
Connections - Terminalsscrew connectors, 0.5 x 2.5 mm²
Package Weight(Lbs)57.0 g
Warranty (In Months)18
Environment Attributes Main
- Ambient Air Temperature For Operation
- -25-70 °C, -25-70 °C
- Ip Degree Of Protection
- IP65 conforming to IEC 60529, IP65 conforming to NF C 20-010
- Recycled Metal Content At Cr Level
- 0 %
- Mercury Free
- Yes
- Circularity Profile
- ENVEOLI2303007EN
- Eu Rohs Directive
- Compliant By Exemption
- Packaging Without Single Use Plastic
- No
- Pep Verification Date
- 2023-08-01
- Psr Version
- PSR-0005-ed2-2016 03 29
Ambient Air Temperature For Storage-40-85 °C, -40-85 °C
Take BackNo
China Rohs RegulationX
Carbon Footprint42.1255466363
Environmental Disclosure"ENVPEP2303007EN"
Packaging Made With Recycled CardboardNo
Pep Code"ENVPEP2303007EN"
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent internal review
General Attributes
- Product Or Component Type
- digital display body
Range Of ProductHarmony
ETIM
- ETIM 8
- EC000204
ETIM 9EC000204
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
Input Attributes
- Logic Input
- positive
