Schneider Electric TM5SDM8DTS Modicon TM5 Discrete I/O Module 4DI/4DO 24V DC, IP20
- MPN: TM5SDM8DTS
- PPN: SCH-TM5SDM8DTS
CAD
$694.83
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This discrete I/O module provides ' discrete inputs with sink discrete input logic and 4 source transistor outputs. It provides a rated supply voltage of 24V DC, a current consumption of 2mA at 5V DCbus, 62.5mA at 24V DC input/output, a maximum power dissipation of 1.51W. This product is part of a flexible and scalable I/O configuration for automation solutions. There is an isolation between channel and bus at 1500V AC for 1min. It is furnished with single wire for electrical connection. It is an IP20 rated product. Its housing colour is white.It weighs 0.022kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Sercos bus interface module. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Austria, Brazil, France
Depth75 mm
Complementary Attributes
- Maximum Voltage Drop
- <0.9 V at 0.1 A output, <0.9 V at 0.1 A output, <0.9 V at 0.1 A output<0.9 V at 0.1 A output, <0.9 V at 0.1 A output, <0.9 V at 0.1 A output
- Maximum Leakage Current
- 25 µA 24 V DC when switched off
Maximum Current Per Output Common0.4 A
Important Information Attributes
- Persona Type Ids
- EU, OM, OM8
- Electromagnetic Compatibility
- electrostatic discharge immunity test, 4 kV on contact IEC 61000-4-2electrostatic discharge immunity test, 8 kV in air IEC 61000-4-2susceptibility to electromagnetic fields, 10 V/m 80...2000 MHz IEC 61000-4-3electrical fast transient/burst immunity test, 1 kV I/O IEC 61000-4-4, electrical fast transient/burst immunity test, 1 kV shielded cable IEC 61000-4-4electrical fast transient/burst immunity test, 2 kV power lines IEC 61000-4-41.2/50 µs shock waves immunity test, 0.5 kV differential mode IEC 61000-4-5, 1.2/50 µs shock waves immunity test, 1 kV common mode IEC 61000-4-5conducted RF disturbances IEC 61000-4-6conducted and radiated emissions CISPR 11
- Response Time
- <= 2 µs from state 0 to state 1 output, <= 2 µs from state 0 to state 1 output, <= 2 µs from state 0 to state 1 output, <= 2 µs from state 1 to state 0 output, <= 2 µs from state 1 to state 0 output, <= 2 µs from state 1 to state 0 output<= 2 µs from state 0 to state 1 output, <= 2 µs from state 0 to state 1 output, <= 2 µs from state 0 to state 1 output, <= 2 µs from state 1 to state 0 output
- Certificate Agency
- EAC, cULus, CE, C-tick
- Local Publishable Date
- 2026-01-12
- Stocking Flag
- Y
- Device Type
- PLC System - PLC Component
- Traceability
- Yes
- Average Life Duration
- 20 year(s)
- With Recycled Cardboard
- No
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 1
- Function Option
- Advanced
- Market Segmentation
- Industrial
- Bearing Track Assembly Possible
- true
- Electrical Connection
- 1 wire
- Network Type
- DC
- Power Dissipation In W
- 1.51 W
- Product Or Component Type
- discrete I/O module
- Radio Standard Gprs
- false
- Radio Standard Umts
- false
- Returnability
- No
- Supporting Protocol For Asi
- false
- Supporting Protocol For Devicenet
- false
- Supporting Protocol For Ethercat
- false
- Supporting Protocol For Interbus
- false
- Supporting Protocol For Lon
- false
- Supporting Protocol For Other Bus Systems
- false
- Supporting Protocol For Profinet Cba
- false
- Supporting Protocol For Profisafe
- false
- Supporting Protocol For Sercos
- false
- Sustainable Packaging
- No
- Vibration Resistance
- 1 gn 8.4-150 Hz) on DIN rail3.5 mm 5-8.4 Hz) on DIN rail
- Certified For Ul Hazardous Location Class Ii
- false
- Certified For Ul Hazardous Location Division 1
- false
- Dc Supply Voltage
- 24-24 V
- Fieldbus Connection Over Separate Bus Coupler Possible
- false
- Digital Inputs Configurable
- false
- Time Delay At Signal Change
- 0.1-0.1 ms
- Width Nominal
- 12.5 mm
- Appendant Operation Agent (Ex Ib)
- false
- Certified For Ul Hazardous Location Group B (Hydrogen)
- false
- Certified For Ul Hazardous Location Group D (Propane))
- false
- Certified For Ul Hazardous Location Group F (Carbonaceous Dust)
- false
- Io-link Master Present
- false
- Rack-assembly Possible
- false
- Supporting Protocol For Data-highway
- false
- Supporting Protocol For Tcp/Ip
- false
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
- Customs Code
- 8538908180
Persona Type NamesEnd User, Original Equipment Manufacturer, OEM - Control Panelbuilder
Local Signalling1 LED (green) for power supply, 1 LED (red) for power supply8 LEDs for input/output status
Switching Frequency<= 16 kHz resistive, <= 16 kHz resistive<= 16 kHz resistive, <= 16 kHz resistive
Local Data StatusPublishable
Return IndicatorN
Stock Policy2
ServiceabilityNo
Field Service DivisionIDIBS
Scope PerimeterAt least in Europe
Without Single Use PlasticYes
Tier Id1
Function Option IdADVANCED
Market Segmentation IdINDUSTRIAL
Product Kit IdentifierN
Current Per Channel0.1 A
Front Installation Possiblefalse
Optical Interface Presentfalse
Product AvailabilityNon-Stock - Not normally stocked in distribution facility
Radio Standard Bluetoothfalse
Radio Standard Gsmfalse
Range Of ProductModicon TM5
Shock Resistance15 gn 11 ms
Supporting Protocol For Canfalse
Supporting Protocol For Devicenet Safetyfalse
Supporting Protocol For Foundation Fieldbusfalse
Supporting Protocol For Knxfalse
Supporting Protocol For Modbusfalse
Supporting Protocol For Profibusfalse
Supporting Protocol For Profinet Iofalse
Supporting Protocol For Safetybus Pfalse
Supporting Protocol For Suconetfalse
Typical Current Consumption2 mA 5 V DC62.5 mA 24 V DC
Certified For Ul Hazardous Location Class Ifalse
Certified For Ul Hazardous Location Class Iiifalse
Certified For Ul Hazardous Location Division 2false
Digital Outputs Configurablefalse
System Accessoryfalse
Short Circuit Protection Outputs Presentfalse
Height Nominal99 mm
Appendant Operation Agent (Ex Ia)false
Certified For Ul Hazardous Location Group A (Acetylene)false
Certified For Ul Hazardous Location Group C (Ethylene))false
Certified For Ul Hazardous Location Group E (Metal Dusts)false
Certified For Ul Hazardous Location Group G (Non Conductive Dust)false
Performance Level According To En Iso 13849-1none
Supporting Protocol For As-interface Safety At Workfalse
Supporting Protocol For Ethernet/Ipfalse
Wall Mounting/Direct Mounting Possiblefalse
Package Weight(Lbs)40.000 g
Warranty (In Months)18
Environment Attributes Main
- Ambient Air Temperature For Operation
- -10-60 °C with derating factor horizontal installation), -10-60 °C with derating factor horizontal installation), -10-60 °C with derating factor horizontal installation), -10-50 °C with derating factor vertical installation), -10-50 °C with derating factor vertical installation), -10-50 °C with derating factor vertical installation)-10-60 °C with derating factor horizontal installation), -10-60 °C with derating factor horizontal installation), -10-60 °C with derating factor horizontal installation), -10-50 °C with derating factor vertical installation)
- Take Back
- No
- Ambient Air Temperature For Storage
- -40-70 °C-40-70 °C
- Ip Degree Of Protection
- IP20
- Packaging Made With Recycled Cardboard
- No
- Relative Humidity
- 5-95 % without condensation
Product CompatibilityPacDrive LMC Pro 2, PacDrive LMC Pro, PacDrive LMC Eco
Recycled Metal Content At Cr Level0 %
Eu Rohs DirectiveUnder investigation
Operating Altitude0...6561.68 ft (0...2000 m)
Packaging Without Single Use PlasticYes
General Attributes
- Product Or Component Type
- discrete I/O module
Range Of ProductModicon TM5
