Square D EJB14050EPD Mini Circuit Breaker 50A 1 Pole 277V AC Bolt-On 30mA Ground Fault
- MPN: EJB14050EPD
- UPC: 785901219477
- PPN: SCH-EJB14050EPD
- UNSPSC: 39121603
CAD
$1047.09
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 50A, 1 pole, and has a operating voltage of 277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes 30 mA ground protection. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
Features
- Used in lighting panelboards
- Superior overload and short circuit protection
- From 15A to 125A ratings
- Troubleshoot faster with Visi-Trip™
- This product is TAA compliant.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Mexico, United States |
|---|---|
| Depth | 4.05 in |
| Compliance | TAA Compliant |
|---|
Complementary Attributes
| Line Rated Current | 50 A |
|---|
| Ue Rated Operational Voltage | 277 V AC |
|---|
Important Information Attributes
| Persona Type Ids | LC, OM |
|---|---|
| Circuit Breaker Application | HACR rated, HID rated |
| Tightening Torque | 3.9-3.9 N.m 2.5-6 mm² (14 AWG...10 AWG), 5.6-5.6 N.m 10-70 mm² (8 AWG...2/0 AWG) |
| Local Publishable Date | 2025-11-19 |
| Device Type | LV equipment - Low voltage circuit breaker |
| Traceability | Yes |
| Average Life Duration | 15 year(s) |
| Scope Perimeter | Outside of Europe |
| End Of Life Doc Ref | ENVEOLI2212008 |
| Reach Full Compliance Status Id | CONTAINS_SVHC |
| Rohs Eur In Scope | No |
| Rohs Eur Full Compliance Status | Not Applicable/Out of Scope |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 2 |
| Function Option | Standard |
| Market Segmentation | Commercial |
| Awg Gauge | 14 AWG...6 AWG copper12 AWG...4 AWG aluminium |
| Electrical Connection | lugs aluminium |
| Holding Current | 630 A |
| Module Type | E-Frame |
| Number Of Poles | 1 |
| Number Of Spaces Required | 2 |
| Product Destination | NF panelboard |
| Range Of Product | 125 A Frame EDB-EGB-EJB |
| Sustainable Packaging | Yes |
| Trip Unit Technology | thermal-magnetic |
| Width Nominal | 1.96 in |
| Nbr. Of Units In Pkg. | 1 |
| Earth Leakage Sensitivity | 30 mA |
| Warranty In Months | 18 |
| Persona Type Names | Contractor, Original Equipment Manufacturer |
|---|---|
| Protection Type | overload, short-circuit |
| Local Data Status | Publishable |
| Return Indicator | N |
| Serviceability | No |
| Field Service Division | PPIBS |
| Weee Scope | Out |
| Eoli Availability Display | Yes |
| Reach Full Compliance Status | Reference contains Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Reference contains Substances of Very High Concern above the threshold |
| Rohs Eur Status | Not Applicable/Out of Scope |
| China Rohs In Scope | No |
| Without Single Use Plastic | Yes |
| Tier Id | 2 |
| Function Option Id | STANDARD |
| Market Segmentation Id | COMMERCIAL |
| Product Kit Identifier | N |
| Device Short Name | EJB |
| Energy Efficiency Optimized | False |
| Local Signalling | trip indicator |
| Mounting Mode | bolt-on |
| Number Of Spaces | 2 |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Product Or Component Type | miniature circuit-breaker |
| Returnability | No |
| Trip Unit Rating | 1800-1800 A |
| Height Nominal | 6.64 in |
| Certificate Agency | cULus |
| Customs Code | 8536200040 |
| Earth Leakage Protection Class | class B |
Environment Attributes Main
| China Rohs Regulation | Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information. |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Circularity Profile | ENVEOLI2212008 |
| Eu Rohs Directive | Not Applicable/Out of Scope |
| Packaging Without Single Use Plastic | Yes |
| Pep Code | ENVPEP2212008EN |
| Take Back | No |
|---|---|
| Ambient Air Temperature For Operation | 40 °C |
| Environmental Disclosure | ENVPEP2212008EN |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
General Attributes
| Product Or Component Type | miniature circuit-breaker |
|---|
| Range Of Product | 125 A Frame EDB-EGB-EJB |
|---|
Contractual Warranty Attributes
| Warranty Period | 18 months |
|---|
| Warranty | 18 months |
|---|
