Schneider Electric XALK84W3BG Harmony Control Station, Yellow Lid, 24V AC/DC, IP65, 1NO 2NC, Polycarbonate

MPN: XALK84W3BG
PPN: SCH-XALK84W3BG

If you can't find the product or are unsure which one you need, please use the Product Selector tool below

$147.82

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This control station with mushroom head push-button for emergency stop function is ideal for situations where quick actions are required for a process or machine to function correctly or where operator movements require maximum ergonomy. Its schematic is clearly distinguishable thanks to clear colors. It is impact resistant, dust resistant, water resistant, corrosion resistant, and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Czechia

Physical Attributes

Color Of Base Of Enclosure	light grey RAL 7035)
Housing Color	yellow

Color Of Cover	yellowyellow RAL 1021)

Important Information Attributes

Persona Type Ids	BM9, EU, LC, OM, OM8, PB, SC, SI, VR
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Cable Entry	1 knock-out for cable entry 0-14 mm, 2 knock-outs for Pg 13 cable gland and ISO M20 0-12 mm
Electrical Durability	1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
Shape Of Screw Head	cross Philips no 1, cross pozidriv No 1slotted flat Ø 4 mm, slotted flat Ø 5.5 mm
Certificate Agency	UL Listed, CSA
Carbon Footprint Of The Distribution Phase [A4]	0.0277404226, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]	0.0012969175, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]	14 kg CO2 eq., 13.5352512
Local Publishable Date	2026-01-12
Stocking Flag	Y
Weee Scope	In
Scope Perimeter	At least in Europe
End Of Life Doc Ref	ENVEOLI2506022EN
Reach Full Compliance Status Id	CONTAINS_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1930
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Compatibility Code	XALK
Contacts Material	silver alloy (Ag/Ni)
Dc Control Voltage	24-24 V
Electrical Insulation Class	class II IEC 61140
Material	polycarbonate
Operating Force	44 N
Operator Profile	red square 32 mm
Positive Opening	with IEC 60947-5-1 appendix K
Product Destination	for XB5 Ø 22 mm control and signalling units
Protective Treatment	TH
Reset	turn to release
Resistance To High Pressure Washer	7000000 Pa 55 °C 0.1 m
Software Version	EIME v5.8.1
Tightening Torque	0.8-1.2 N.m IEC 60947-1
Vibration Resistance	5 gn (f= 10-500 Hz) conforming to IEC 60068-2-625 mm peak to peak (f= 2-10 Hz) conforming to IEC 60068-2-6
Ac Control Voltage 50 Hz	24-24 V
Number Of Command Positions	1
Number Of Contacts As Normally Open Contact	1
Color Of Cover	yellowyellow RAL 1021)
Pep Code	ENVPEP2506022EN
Pep Verification Date	2018-09-01
Psr Version	PSR-0005-ed2-EN-2016 03 29
Data Source	extrapolated product
Functional-unit Quantity	1
Reference Lifetime In Y	20
Energy Model - Installation [A5]	Electricity mix; AC; <lt/> 1kV; EU-27
Energy Model - End Of Life [C1-c4]	Electricity mix; AC; <lt/> 1kV; EU-27
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Uimp] Rated Impulse Withstand Voltage	6 kV IEC 60947-1
Connections - Terminals	screw clamp terminals, = 1 x 0.22 mm² without cable end IEC 60947-1
Emergency Power Off (Epo)	no
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8536509035

Persona Type Names	Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market Segmentation	Commercial, Industrial
Control Station Application	emergency switching off function, emergency stop function
Electrical Reliability	λ < 10exp(-6) 5 V, 1 mA IEC 60947-5-4, λ < 10exp(-8) 17 V, 5 mA IEC 60947-5-4
Shock Resistance	30 gn 18 ms) half sine wave acceleration IEC 60068-2-2750 gn 11 ms) half sine wave acceleration IEC 60068-2-27, 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
[Ie] Rated Operational Current	3 A 240 V, AC-15, A600 IEC 60947-5-16 A 120 V, AC-15, A600 IEC 60947-5-10.1 A 600 V, DC-13, Q600 IEC 60947-5-10.27 A 250 V, DC-13, Q600 IEC 60947-5-10.55 A 125 V, DC-13, Q600 IEC 60947-5-1, 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
Carbon Footprint Of The End-of-life Phase [C1 To C4]	0 kg CO2 eq., 0.0405979209
Carbon Footprint Of The Manufacturing Phase [A1 To A3]	1 kg CO2 eq., 1.3993612815
Local Data Status	Publishable
Return Indicator	Y
Stock Policy	1
Weee Product Category	5
Eoli Availability Display	Yes
Reach Full Compliance Status	Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive	Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant By Exemption
Rohs Eur Full Compliance Status	Compliant By Exemption
China Rohs Label	7
Without Single Use Plastic	Yes
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Contact Operation	slow-break
Control Station Composition	1 mushroom head push-button, red 1 NO + 2 NC
Device Short Name	XALK
Housing Material	plastic
Mechanical Durability	300000 cycles
Operating Travel	1.5 mm NC changing electrical state)4.3 mm total travel)
Operators Description	red unmarked 1 NO + 2 NC
Product Availability	Stock - Normally stocked in distribution facility
Product Or Component Type	complete control station
Range Of Product	Harmony XALK
Resistance To Electrostatic Discharge	4 kV on contact (on metal parts) IEC 61000-4-28 kV in free air (in insulating parts) IEC 61000-4-2
Returnability	Yes
Sustainable Packaging	Yes
Total Lifecycle Carbon Footprint	15 kg CO2 eq.
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Ac Control Voltage 60 Hz	24-24 V
Number Of Contacts As Normally Closed Contact	2
Color Of Base Of Enclosure	light grey RAL 7035)
Housing Color	yellow
Database Version	2016-11
Pcr Version	PCR-ed3-EN-2015 04 02
Type Of Verification For The Pep	Independent internal review
Functional-unit Description	To provide Stop, Start or Combined functions on 10A electrical load for 20 years at 30% use rate with 0.5W power use.
Functional-unit Unit	unité (unit)
Energy Model - Manufacturing [A1-a3]	Energy model used: France
Energy Model - Use [B6]	Electricity mix; AC; <lt/> 1kV; EU-27
Recyclability Potential In %	18
[Ui] Rated Insulation Voltage	600 V 3)IEC 60947-1
[Us] Rated Supply Voltage	24 V AC/DC
Short-circuit Protection	10 A cartridge fuse gG IEC 60947-5-1
Number Of Mushroom-shaped Push-buttons	1
Package Weight(Lbs)	213.000 g
Warranty (In Months)	18
