Balluff BIC 2I3-P2A50-Q40KFU-EPX0-002-M4CA Inductive couplers for signal transmission BIC 2I3-P2A50-Q40KFU-EPX0-002-M4CA
- MPN: BIC 2I3-P2A50-Q40KFU-EPX0-002-M4CA
- PPN: BAL-BIC007K
CAD
$1175.98
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Our inductive coupler system is designed for up to eight sensor signals and eight actuator drive signals. The system is bi-directional, which means it transmits signals in both directions. Its remote unit can drive on an individual basis and operate clamping units. From the base, up to eight signals are transferable, and four channels can be driven independent of each other.
Documentation & Downloads
Specifications
Key Specifications
| Function | Signal transmission |
|---|---|
| Digital inputs | 8x PNP |
| Component | Remote |
| Output voltage | 24 VDC |
| Housing material | PBTP |
| Ambient temperature | -5-65 °C |
| Signal type | unidirectional |
|---|---|
| Transmission distance | 0-5 mm |
| Connection | Connector, M12x1, 12-pin, 0.20 m, PUR |
| Rated output current | 500 mA |
| Dimension | 40 x 40 x 52 mm |
| IP rating | IP67 |
