Balluff BNI IOL-302-S02-Z013 IO-Link Sensor/Actuator Hub, 16 Digital Inputs, IP67, Zinc Housing
- MPN: BNI IOL-302-S02-Z013
- PPN: BAL-BNI0046
CAD
$565.30
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Designed for robust industrial applications, the IO-Link sensor/actuator hub from Balluff offers exceptional connectivity and control capabilities. With a rapid transfer rate of 38.4 kBaud and the ability to handle 16 digital inputs and outputs, this hub ensures efficient data processing with a minimum cycle time of just 6.2 ms. Constructed from durable zinc die-cast material, it is built to withstand challenging environments, maintaining an IP67 rating when properly installed. The device operates within a voltage range of 18-30.2 VDC and features multiple M12 connection ports, making it a versatile solution for integrating sensors and actuators in automated systems.
Documentation & Downloads
Specifications
Additional
| Digital Inputs | 16x PNP, Type 3 |
|---|---|
| Transfer Rate | COM2 (38.4 kBaud) |
| Operating Voltage | 18-30.2 VDC |
| Ambient Temperature | -5 to 55 C |
| Interface | IO-Link 1.1 |
| Connection (COM 1) | M12x1-Male, 4-pin, A-coded |
| Connection Ports | 8x M12x1-Female, 5-pin, A-coded |
| Digital Outputs | 16x PNP |
|---|---|
| Process Data Cycle Minimum | 6.2 ms |
| Output Current Maximum | 2 A |
| IP Rating | IP67 when threaded in |
| Dimension | 68 x 32.4 x 181.5 mm |
| Connection (Supply Voltage IN) | 7/8"-Male, 5-pin |
| Housing Material | Zinc, Die casting |
