Balluff BNI IOL-309-000-K024 IO-Link sensor/actuator hubs BNI IOL-309-000-K024
- MPN: BNI IOL-309-000-K024
- PPN: BAL-BNI004K
CAD
$222.10
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Our I/O modules with their robust housings are suitable for use in a harsh industrial environment. The I/O hubs are based on M12 or M8 plug connections and are easy and economical to install and maintain.
Documentation & Downloads
Specifications
Key Specifications
| Interface | IO-Link 1.0 |
|---|---|
| Connection (COM 1) | Screw/plug-in terminals |
| Connection ports | Screw/plug-in terminals |
| Digital outputs | 8x PNP |
| Output current max. | 350 mA |
| Dimension | 48.6 x 42.6 x 84 mm |
| IP rating | IP20 |
| Process data cycle min. | 3.0 ms |
| Process data OUT | 1 bytes |
| Operating voltage Ub | 18-30.2 VDC |
|---|---|
| Connection (supply voltage IN) | Screw/plug-in terminals |
| Digital inputs | 8x PNP, Type 2 |
| Configurable inputs/outputs | yes |
| Housing material | PA 6.6, UL94V-0 |
| Ambient temperature | -5-50 °C |
| Transfer rate | COM2 (38.4 kBaud) |
| Process data IN | 1 byte Input |
