Balluff BNI IOL-310-000-K025 IO-Link sensor/actuator hubs BNI IOL-310-000-K025
- MPN: BNI IOL-310-000-K025
- PPN: BAL-BNI004L
CAD
$218.70
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Our I/O modules with their robust housings are suitable for use in a harsh industrial environment. The I/O hubs are based on M12 or M8 plug connections and are easy and economical to install and maintain.
Documentation & Downloads
Specifications
Key Specifications
- Interface
- IO-Link 1.0
- Connection (COM 1)
- Screw/plug-in terminals
- Connection ports
- Screw/plug-in terminals
- Digital outputs
- 16x PNP
- Output current max.
- 350 mA
- Dimension
- 79 x 42.6 x 84 mm
- IP rating
- IP20
- Process data cycle min.
- 12.0 ms
- Process data OUT
- 2 bytes
Operating voltage Ub18-30.2 VDC
Connection (supply voltage IN)Screw/plug-in terminals
Digital inputs16x PNP, Type 2
Configurable inputs/outputsyes
Housing materialPA 6.6, UL94V-0
Ambient temperature-5-50 °C
Transfer rateCOM2 (38.4 kBaud)
Process data IN2 bytes
