Telemecanique Sensors 9007AO18 Limit switch, 9007, snap 600 VAC 15amp ao +options
- MPN: 9007AO18
- UPC: 785901807612
- PPN: TES-9007AO18
- UNSPSC: 39122213
CAD
$397.82
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Limit switch, 9007, snap 600 VAC 15amp ao +options
Documentation & Downloads
Specifications
Key Specifications
- Series Name
- heavy duty
- Range Of Product
- 9007
- Product Or Component Type
- limit switch
Body Typefixed
Product Specific Applicationprecision
Device Short Name9007AW
Complementary
- Switch Actuation
- from left convertible to right || CCW convertible to CW
- Type Of Approach
- lateral approach, 1 direction programmable
- Movement Of Operating Head
- rotary
- Terminals Description Iso N°1
- (5-6)NC || (7-8)NO || (3-4)NO || (1-2)NC
- Positive Opening
- without
- Tripping Angle
- 5 °
- Contact Operation
- snap action
- [Ie] Rated Operational Current
- 0.6 A 600 V AC, B600 NEMA rating designation || 0.75 A 480 V AC, B600 NEMA rating designation || 1.5 A 240 V AC, B600 NEMA rating designation || 3 A 120 V AC, B600 NEMA rating designation || 0.1 A 250 V DC || 0.2 A 125 V DC
- Contacts Material
- silver contacts
- Operator Profile
- rotary head
- [Ithe] Conventional Enclosed Thermal Current
- 10 A
- Contacts Type And Composition
- 2(NC-NO) DPDT-DB
- Depth
- 1.38 in
- Material
- metal
- Type Of Operator
- spring return without operating lever cast zinc
- Repeat Accuracy
- +/- 0.002 in linear travel of cam on 1.38 in long lever arm
Maximum Displacement Angle30 °
Height3.47-3.47 in
Mounting Modeopen type
[Ui] Rated Insulation Voltage600 V 3)UL 508 contact block || 600 VCSA C22.2 No 14 contact block
Electrical Connection1-2 screw-clamp terminals AWG 22...AWG 12)
Number Of Steps1
Operator Materialcast zinc
Fixing Modeby the body
Maximum Actuation Speed130 ft/min with 30° cam angle, levers only || 90 ft/min with 45° cam angle, levers only
Body Materialcast zinc
Contact FormForm ZZ
Width2.38 in
Minimum Torque For Tripping2.75 lbf.in
Net Weight0.1 lb(US)
Number Of Poles2
Environment
- Ambient Air Temperature For Operation
- 0-185 °F
- Nema Degree Of Protection
- NEMA 1 Nema type 250
- Ip Degree Of Protection
- IP20 conforming to IEC 60529
Ambient Air Temperature For Storage0-185 °F
Protective Treatmentepoxy powder coat
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Eu Rohs Directive
- Not applicable, out of EU RoHS legal scope
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Reach RegulationReference contains Substances of Very High Concern above the threshold
