Pass & Seymour PS30AC2HP Manual Controller, 30A 277V, Double-Pole, HP Rated, NEMA 3R Enclosure
- MPN: PS30AC2HP
- UPC: 785007195972
- PPN: P-S-PS30AC2HP
CAD
$97.16
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Manual Controller, 30A 277V, Double-Pole, HP Rated, NEMA 3R Enclosure
Features
- High horsepower rating, up to 3HP for heavy-duty applications. Compact design provides ease of installation. Single piece moveable and stationary contact arms with oversized silver cadmium buttons provides excellent continuity and long life.
- Made in USA. Box lug terminals. Wire pockets and thick wall arc barriers. Cold-rolled steel NEMA 3R enclosure with polyester urethane finish conforms to OSHA lockout requirements.
- Type 3R enclosure has 2-1/2 inch, 3/4 inch, and 1 inch concentric knockouts on bottom. Accepts #4 AWG. cULus listed.
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
Documentation & Downloads
Specifications
Key Specifications
- Depth
- 1.073 in
- Color
- Brown
- Width
- 1.32 in
- Country of Origin
- Mexico
- Type
- Switch
- Load Type
- LED
- Amperage
- 30.0 A
- Voltage
- 120.0 V
- Load Type
- Halogen
- Switch Type
- Toggle
- Indoor/Outdoor
- Indoor
- Load Type
- Incandescent
- Number of Switches
- 1.0
- Throw Type
- Double Throw
- Features
- Chemical Resistant
- Application Sector
- Commercial
- Load Rating
- 30 A @ 120/277 VAC
- Horsepower Rating
- 2 HP @ 240 VAC
- Wire Connection Type
- Screw Terminals
- Terminal Accommodation
- #14 AWG - #10 AWG
Height3.281 in
FinishMatte
MaterialThermoplastic
Product LinePass & Seymour
Load TypeCFL
StandardUL 20
Load TypeXenon
StandardFEDSPEC
Number of Gangs1
Load TypeUniversal
Load TypeFluorescent
Mounting TypeWall Box
Wall Plate IncludedNo
Requires Neutral WireNo
Number of PolesDouble Pole
Application SectorIndustrial
Horsepower Rating2 HP @ 120 VAC
Connection LocationBack and Side
Warranty Type1-Year Limited Warranty
Special FeaturesHigh strength toggle, heavy duty toggle bumpers, locking support
