Square D QO2110VH Mini Circuit Breaker, 110A, 2 Pole, 120/240VAC, 22kA Breaking Capacity
Square D QO2110VH Mini Circuit Breaker, 110A, 2 Pole, 120/240VAC, 22kA Breaking Capacity
- MPN: QO2110VH
- UPC: 785901054931
- PPN: SCH-QO2110VH
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$328.37/ EA
Description
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 110A at 120/240VAC. This unit provides 22kA breaking capacity and plug in mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
Specifications
- Current Rating
- 110 A
- Breaking Capacity
- 22 kA 120/240 V AC 50/60 Hz
- Mounting Type
- Plug-in
- Electrical Connection
- Box lugs
- Tightening Torque
- 5.6 N.m
- Width
- 38 mm
- Net Weight
- 0.336 kg
- Ambient Rating
- 40 B0C
- Halogen Content
- Halogen free
- Sustainable Offer Status
- Green Premium product
Voltage120/240 V AC
Number of Poles2P
Circuit Breaker TypeStandard
Wire SizeAWG 4...300 kcmil copper or aluminum
Height89 mm
Depth74 mm
CertificationsUL Listed, CSA Certified
RoHS ComplianceCompliant with Exemptions
Mercury FreeYes
Range of ProductQO
