Square D QOU220VH Mini Circuit Breaker 25A 2 Pole 120/240V AC 22kA
- MPN: QOU220VH
- UPC: 785901579830
- PPN: SCH-QOU220VH
CAD
$434.52
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
QO™ and QOU Miniature Circuit Breakers, QOU220VH, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit.QOU breakers are able to operate up to 22 kA short ciruit current. .
Documentation & Downloads
Specifications
Additional
- Voltage
- 120/240 V AC
- Circuit Breaker Type
- standard
- Short Circuit Current Rating
- 22 kA
- Electrical Connection
- slotted box lugs, line and load side
- AWG Gauge
- AWG 14 to AWG 2 aluminum/copper
- Height
- 4.05 in
- Depth
- 2.95 in
- Mercury Free
- Yes
- Product Certifications
- IEC, UL Listed, CSA
- China Rohs Regulation
- Out of China RoHS scope
- Rohs Exemption Information
- Yes
- Warranty
- 18 months
- Product Or Component Type
- miniature circuit-breaker
- Country of Origin
- MX
Current Rating20 A
Circuit Breaker ApplicationHACR rated
Pole Count2
Mounting Modeunit mount
Tightening Torque45 lbf.in (5.08 N.m)
Width1.5 in
Toxic Heavy Metal FreeYes
Halogen Content PerformanceHalogen free product
Eu Rohs DirectiveCompliant with Exemptions
Reach RegulationContains SVHC above threshold
Sustainable Offer StatusGreen Premium product
Range Of ProductQOU
Circularity ProfileN/A
