ABB CL-502Y PILOT LIGHT CL-502Y 24V a.c./d.c.
- MPN: CL-502Y
- UPC: 73205002503030
- PPN: ABB-CL-502Y
CAD
$12.60
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Compact Pilot Light - Pilot light head - Yellow - Illuminated - Lamptype: LED 24V AC / DC
Specifications
Additional Information
| Actuator Type | Pilot light head |
|---|---|
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20Front IP66Front IP67Front IP69K |
| Lamp Type | LED 24V AC / DC |
| Product Main Type | CL |
| Product Range | Compact |
| Rated Current (In) | 15 mA |
| Rated Operational Voltage | 24 V AC/DC |
| Color | Yellow |
|---|---|
| Illumination | Illuminated |
| Order Multiple | 1 piece |
| Product Name | Pilot Light |
| Product Type | CL |
| Rated Frequency (f) | Supply Circuit 50 60 Hz |
| RoHS Date | 0626 5 |
Dimensions
| Product Net Width | 0.03 m |
|---|---|
| Product Net Depth / Length | 0.055 m |
| Product Net Height | 0.03 m |
|---|---|
| Product Net Weight | 0.022 kg |
Container Information
| Package Level 1 Units | 10 piece |
|---|---|
| Package Level 1 Height | 0.03 m |
| Package Level 1 Gross Weight | 0.022 kg |
| Package Level 1 Width | 0.1 m |
|---|---|
| Package Level 1 Depth / Length | 0.1 m |
Classifications
| ETIM 4 | EC002024 - Accessories for control circuit devices |
|---|---|
| Object Classification Code | E |
| ETIM 5 | EC002024 - Accessories for control circuit devices |
|---|---|
| UNSPSC | 39121500 |
Environmental
| Ambient Air Temperature | Operation -25 ... +70 °CStorage -30 ... +85 °C |
|---|
| RoHS Status | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
|---|
Ordering
| E-Number (Sweden) | 3711344 |
|---|---|
| Minimum Order Quantity | 10 piece |
| EAN | 7320500250303 |
|---|---|
| Customs Tariff Number | 85369001 |
