ABB CL-513W PILOT LIGHT CL-513W 110-130V a.c.
- MPN: CL-513W
- UPC: 73205002593680
- PPN: ABB-CL-513W
CAD
$12.60
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Compact Pilot Light - Pilot light head - White - Illuminated - Lamptype: LED 110-130V AC
Specifications
Additional Information
- Actuator Type
- Pilot light head
- Degree of Protection
- acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20Front IP66Front IP67Front IP69K
- Lamp Type
- LED 110-130V AC
- Product Name
- Pilot Light
- Product Type
- CL
- Rated Frequency (f)
- Supply Circuit 50 60 Hz
- RoHS Date
- 0626 5
ColorWhite
IlluminationIlluminated
Product Main TypeCL
Product RangeCompact
Rated Current (In)15 mA
Rated Operational Voltage110 ... 130 2G
Dimensions
- Product Net Width
- 0.03 m
- Product Net Depth / Length
- 0.055 m
Product Net Height0.03 m
Product Net Weight0.022 kg
Container Information
- Package Level 1 Units
- 10 piece
- Package Level 1 Height
- 0.03 m
- Package Level 1 Gross Weight
- 0.022 kg
Package Level 1 Width0.1 m
Package Level 1 Depth / Length0.1 m
Classifications
- ETIM 4
- EC002024 - Accessories for control circuit devices
- Object Classification Code
- E
ETIM 5EC002024 - Accessories for control circuit devices
UNSPSC39121500
Environmental
- Ambient Air Temperature
- Operation -25 ... +70 °CStorage -30 ... +85 °C
RoHS StatusFollowing EU Directive 2002/95/EC August 18, 2005 and amendment
Ordering
- E-Number (Sweden)
- 3711378
- Minimum Order Quantity
- 10 piece
EAN7320500259368
Customs Tariff Number85369001
