Pass & Seymour PT5362AGRY PlugTail® 20A 125V Duplex Receptacle, Gray, 1.625 Inch Width, 2.75 Inch Height

MPN: PT5362AGRY
UPC: 785007860320
PPN: P-S-PT5362AGRY
UNSPSC: 39121406

$42.95

Available to Order from Manufacturer

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

PlugTail® Industrial Extra Heavy-Duty Spec Grade Receptacles, 20A, 125V PlugTail® devices and connectors mean that device installation is the same regardless of skill level of the installer. The UL-Listed connectors are keyed to ensure proper wiring installation into each receptacle.

Features

.036 inch thick, brass, triple-wipe power contacts for lasting retention.
Illuminated face indicates power to receptacle and makes it easy to identify receptacle in dark applications.
Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
Crimped and welded contacts.
Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
Large brass contacts snugly terminate on device blade terminals.
Auto-ground clip assures positive ground.
For covering patents, see www.legrand.us/patents.
For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
PlugTail™ Connector: #12 AWG, THHN, copper conductor, 6" leads, stripped, solid or stranded, for use with PlugTail Receptacles only

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Mexico
Height	2.75 in
Color	Gray
Amperage	20.0 A
Indoor/Outdoor	Indoor
Environmental Conditions	Flammability: UL94 V2
Dielectric Strength	Withstands 2000V minimum
Number of Wires	3.0
Wire Size	12 AWG
Voltage	125.0 V
Operating Temperature Max	60.0 °C
Wall Plate Included	No
Operating Temperature	-40°-60°C
Operating Temperature Min	-40.0 °C

Depth	0.86 in
Width	1.625 in
Product Line	Pass & Seymour
Number of Poles	Double Pole
Number of Receptacles	2.0
Special Features	Exclusive patented feature, circuit label on face allows permanent circuit identification. .036 inch thick, brass, triple-wipe power contacts for lasting retention. Strap tabs wrap around and lock down on face to prevent strap from separating from face and back body. Two drive screws anchor strap to back body and face. No exposed terminals create a finger safe application before, during, and after installation. Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections. Crimped and welded contacts. Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing. Large brass contacts snugly terminate on device blade terminals. Pre-stripped connector leads fasten to conductors, easier than standard pigtails. Exclusive patented feature, circuit label on back allows permanent circuit identification. Auto-ground clip assures positive ground.
Application Sector	Commercial; Industrial
Standard	cULus UL498; FEDSPEC
Connection Location	Back Only
Warranty Type	1-Year Limited Warranty
Wire Connection Type	PlugTail
Features	Single Piece Plated Steel Mounting Strap
Outlet Type	Straight Blade
NEMA Configuration Code	5-20R
