Schneider Electric 9001SKT1LRR31 Harmony Push-to-Test Pilot Light, 30mm, Red LED, 110-120V
- MPN: 9001SKT1LRR31
- UPC: 785901580805
- PPN: SCH-9001SKT1LRR31
CAD
$252.63
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
The Schneider Electric Harmony Push-to-Test Pilot Light is an essential component for automation and control applications, offering both functionality and reliability. Featuring a vibrant red LED, this 30mm pilot light ensures visibility in a variety of environments while operating on a voltage range of 110-120V. Its push-to-test feature allows for easy verification of the light's operation, making it an ideal choice for panel builders and industrial settings where operational status indicators are crucial. With Schneider Electric s commitment to quality, this pilot light is designed to enhance safety and efficiency in your control systems.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Mexico, United States |
|---|
Physical Attributes
| Cad Overall Depth | 42 mm |
|---|---|
| Cad Overall Width | 54 mm |
| Light Source Color | red |
| Cad Overall Height | 70 mm |
|---|---|
| Size | 30 mm |
Important Information Attributes
| Persona Type Ids | BM9, EU, LC, OM, OM8, PB, SC, SI, VR |
|---|---|
| Market Segmentation Id | COMMERCIAL, INDUSTRIAL |
| Certificate Agency | NEMA, UL 508 |
| Local Data Status | Publishable |
| Return Indicator | N |
| Stock Policy | 2 |
| Weee Product Category | 5 |
| Eoli Availability Display | Yes |
| Reach Full Compliance Status | Reference contains Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Reference contains Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| China Rohs Label | 1 |
| Without Single Use Plastic | Yes |
| Tier Id | 2 |
| Function Option Id | STANDARD |
| Product Kit Identifier | N |
| Bulb Base | BA 9s |
| Contacts Type And Composition | 1 C/O |
| Electrical Shock Protection Class | class II conforming to IEC 61140 |
| Lens Type | fresnelfresnel plastic |
| Light Source | LEDRed LED |
| Operating Mode | push-to-test |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Protective Treatment | TC |
| Returnability | No |
| Shape Of Signaling Unit Head | round |
| Supply Frequency | 50...60 Hz |
| Tightening Torque | 0.8-0.8 N.m IEC 60947-1 |
| Light Source Color | red |
| [Ith] Conventional Free Air Thermal Current | 10 A |
| [Uimp] Rated Impulse Withstand Voltage | 2.5 kV IEC 60947-1 |
| Connections - Terminals | screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1 |
| Nbr. Of Units In Pkg. | 1 |
| Take-back | No |
| Customs Code | 8531809026 |
| Persona Type Names | Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner |
|---|---|
| Market Segmentation | Commercial, Industrial |
| [Us] Rated Supply Voltage | 110...120 V, 110...120 V AC 50/60 Hz |
| Local Publishable Date | 2026-01-12 |
| Stocking Flag | Y |
| Weee Scope | In |
| Scope Perimeter | Outside of Europe |
| End Of Life Doc Ref | ENVEOLI2503027EN |
| Reach Full Compliance Status Id | CONTAINS_SVHC |
| Rohs Eur In Scope | No |
| Rohs Eur Conformity Date | 1930 |
| China Rohs In Scope | Yes |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 2 |
| Function Option | Standard |
| Bezel Material | plastic |
| Compatibility Code | 9001SK |
| Device Short Name | 9001SK |
| Lens Material | polycarbonate |
| Light Block Supply | via integral transformerdirect 110...120 V AC 50/60 Hz |
| Mounting Diameter | 30 mm |
| Operating Position | any position |
| Product Or Component Type | push-to-test pilot light |
| Range Of Product | Harmony 9001SK |
| Shape Of Screw Head | cross slotted |
| Shock Resistance | 50 gn IEC 60068-2-27 |
| Sustainable Packaging | Yes |
| Vibration Resistance | 7 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| Pep Code | ENVPEP2503027EN |
| [Ui] Rated Insulation Voltage | 250 V 2)IEC 60947-1 |
| Cap/Operator Or Lens Colour | red |
| Short-circuit Protection | 10 A cartridge fuse IEC 60947-5-1 |
| Package Weight(Lbs) | 226.796 g |
| Warranty (In Months) | 18 |
Environment Attributes Main
| Ambient Air Temperature For Operation | -25-70 °C, -25-70 °C |
|---|---|
| Ip Degree Of Protection | IP66 IEC 60529, IP65/IP66 |
| Take Back | No |
| China Rohs Regulation | X |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP2503027EN |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Ambient Air Temperature For Storage | -40-70 °C, -40-70 °C |
|---|---|
| Nema Degree Of Protection | NEMA 1, NEMA 12, NEMA 13, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X |
| Recycled Metal Content At Cr Level | 0 % |
| Toxic Heavy Metal Free | Yes |
| Circularity Profile | ENVEOLI2503027EN |
| Eu Rohs Directive | Compliant |
| Packaging Without Single Use Plastic | Yes |
| Pep Code | ENVPEP2503027EN |
General Attributes
| Product Or Component Type | push-to-test pilot light |
|---|
| Range Of Product | Harmony 9001SK |
|---|
ETIM
| ETIM 8 | EC000272 |
|---|
| ETIM 9 | EC000272 |
|---|
Contractual Warranty Attributes
| Warranty Period | 18 months |
|---|
| Warranty | 18 months |
|---|
