Square D 9001SKT38LY Push-to-Test Pilot Light Head, 30 mm, Yellow LED, 120V AC/DC
- MPN: 9001SKT38LY
- UPC: 785901398806
- PPN: SCH-9001SKT38LY
CAD
$237.18
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Experience reliable monitoring with the push-to-test pilot light head designed by Schneider Electric. This 30 mm model features a bright yellow LED and operates on a versatile 120V AC/DC power supply, ensuring visibility and efficiency in various automation and control applications. Its robust construction is tailored for seamless integration within pilot devices, making it an essential component for enhancing operational safety and performance. Whether used in industrial settings or sophisticated control panels, this pilot light head guarantees user-friendly testing functionality, providing instant feedback and ensuring system reliability.
Documentation & Downloads
Specifications
Additional
- Rated Supply Voltage
- 120 V AC/DC
- Short-circuit Protection
- 10 A cartridge fuse IEC 60947-5-1
- Rated Impulse Withstand Voltage
- 2.5 kV IEC 60947-1
- Operating Mode
- push-to-test
- Mounting Diameter
- 30 mm
- Overall Height
- 70 mm
- Net Weight
- 0.181 kg
- Bezel Material
- plastic
- Tightening Torque
- 0.8 N.m IEC 60947-1
- Connection Terminals
- screw clamp, 1 x 0.22 to 2 x 1.5 mm² IEC 60947-1
- Protective Treatment
- TC
- NEMA Degree of Protection
- NEMA 1, 2, 3, 3R, 4, 4X, 12, 13
- Shock Resistance
- 50 gn IEC 60068-2-27
- Ambient Air Temperature for Storage
- -40 to 70 °C
- Product Certifications
- NEMA, UL 508
- Mercury Free
- Yes
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Toxic Heavy Metal Free
- Yes
- Environmental Disclosure
- ENVPEP121113EN
- Product Or Component Type
- head for push-to-test pilot light
- Device Short Name
- 9001SK
Conventional Thermal Current10 A
Rated Insulation Voltage250 V IEC 60947-1
Operating Positionany position
Size30 mm
Overall Width54 mm
Overall Depth42 mm
Shape Of Signaling Unit Headround
Bulb BaseBA 9s
Screw Head Shapecross slotted
Electrical Shock Protection Classclass II IEC 61140
IP Degree of ProtectionIP66 IEC 60529
Vibration Resistance7 gn (2 to 500 Hz) IEC 60068-2-6
Ambient Air Temperature for Operation-25 to 70 °C
Standards ComplianceIEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, JIS C 8201-1, JIS C 8201-5-1, JIS C 852, CSA C22.2 No 14, UL 508
Rohs Exemption InformationYes
Reach Free Of SvhcYes
China Rohs RegulationX
Sustainable Offer StatusGreen Premium product
Range Of ProductHarmony 9001SK
Contacts Type And Composition1 C/O
Circularity ProfileENVEOLI121109EN
