APC AP7552 Rack PDU 16A 230V Zero U with (20) C13 & (4) C19 Ports, 10 ft Cord Length
- MPN: AP7552
- UPC: 731304207900
- PPN: APC-AP7552
CAD
$644.78
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
It is a basic rack PDU with a Zero U vertical mounting design. It supports a maximum input current of 16A and operates at 230V. The PDU features 20 IEC 60320 C13 outlets and 4 IEC 60320 C19 outlets, providing flexibility for connecting various IT equipment. It includes a 10-foot power cord with an IEC 60309 16A plug. The unit is designed for reliable power distribution and includes an installation guide, rack mounting brackets, and a toolless mounting kit.
Features
- Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
- Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
- Features 20 C13 and 4 C19 outlets for comprehensive power distribution
- Zero U design for efficient use of rack space
- Supports up to 16A, 230V power distribution
- Toolless mounting for quick and hassle-free setup
Documentation & Downloads
Specifications
Additional
| Voltage | 200 V, 208 V, 230 V |
|---|---|
| Load Capacity | 3680 VA |
| Nominal Output Voltage | 230 V |
| Height | 63.74 in (161.9 cm) |
| Depth | 1.73 in (4.4 cm) |
| Rack Units | 0U |
| Outlet Type and Quantity | 20 IEC 60320 C13, 4 IEC 60320 C19 |
| Mounting Mode | Rack-mounted |
| RoHS Compliance | Compliant |
| Reach | Free of SVHC above threshold |
| Operating Temperature Range | 32 to 113 F (0 to 45 C) |
| Operating Humidity | 5 to 95 % |
| Operating Altitude | 0 to 10000 ft |
| Amperage | 16A |
|---|---|
| Input Frequency | 50/60 Hz |
| Cord Length | 10 ft (3.05 m) |
| Width | 2.20 in (5.6 cm) |
| Weight | 10.71 lb (4.86 kg) |
| Input Connection Type | IEC 60320 C20 |
| Mounting Position | side, vertical |
| Material | Not specified |
| Approvals | CE, GOST, IRAM, VDE |
| Lead Free | Yes |
| Storage Temperature Range | -13 to 149 F (-25 to 65 C) |
| Storage Humidity | 5 to 95 % |
| Storage Altitude | 0 to 50000 ft |
