APC AP7968B Rack PDU, Switched, Zero U, 12.5 kW, 208 V, 21 C13 & 3 C19, 3 ft Cord
- MPN: AP7968B
- UPC: 731304331650
- PPN: APC-AP7968B
CAD
$3402.99
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
It is a switched rack PDU with a maximum current capacity of 35A and an input voltage of 208V. It features 21 IEC 60320 C13 and 3 IEC60320 C19 outlets. The PDU has a ZeroU form factor and a cord length of 3 feet. It supports remote monitoring and user-defined alarms, with outlet-level on/off switching capabilities. The unit is UL Listed and CSA certified, ensuring high safety and performance standards.
Features
- Status available to customers both in the data center and remotely
- Enables a quick recovery from overload events.
- Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
- Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
- It can handle a maximum power capacity of 12.5kW, making it suitable for high-power applications
- It features 21 IEC C13 outlets and 3 IEC C19 outlets, providing extensive connectivity options
- Designed for ZeroU mounting, it saves valuable rack space and allows for efficient cable management
- Supports remote monitoring and control, enabling users to manage power distribution from a distance
Documentation & Downloads
Specifications
Additional
| Voltage | 208 V 3 phase |
|---|---|
| Power Capacity | 12.5 kW |
| Rack Height | 0U |
| Width | 2.20 in (5.6 cm) |
| Depth | 3.50 in (8.9 cm) |
| Cord Length | 3 ft (0.91 m) |
| Country of Origin | India |
| Certifications | UL Listed, cUL Listed, CSA, Industry Canada |
| Max Line Current | 35 A |
|---|---|
| Input Frequency | 50/60 Hz |
| Mounting Style | Side, Vertical (Zero U) |
| Height | 70.00 in (177.8 cm) |
| Weight | 17.81 lb (8.08 kg) |
| Number of Outlets | 24 (21 C13, 3 C19) |
| Material Compliance | RoHS Compliant (with Exemptions), Lead Free, Mercury Free, REACH SVHC Free |
