APC AP7540 Rack PDU Zero U Power Distribution, 20A, 208V, (20)C13 & (4)C19, 10.71 lb

MPN: AP7540
UPC: 731304207931
PPN: APC-AP7540

$644.78

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

It is a basic rack PDU with a Zero U vertical mounting design. It supports a maximum input current of 20A and operates at 208V. The PDU features 20 IEC 60320 C13 outlets and 4 IEC 60320 C19 outlets, providing flexibility for connecting various IT equipment. It includes a 10-foot power cord with a NEMA L6-20P plug. The unit is designed for reliable power distribution and includes an installation guide, rack mounting brackets, and a toolless mounting kit.

Features

Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
Supports up to 20A, 208V power distribution
Equipped with 20 C13 and 4 C19 outlets for versatile power connections
Zero U design saves rack space
Built to withstand demanding data center environments

Documentation & Downloads

Specifications

Additional

Voltage	200 V, 208 V, 230 V
Load Capacity	3300 VA
Mounting Type	Side, Vertical, Rack-mounted
Cord Length	10 ft (3.05 m)
Width	2.20 in (5.6 cm)
Weight	10.71 lb (4.86 kg)
Approvals	UL Listed, cUL Listed

Amperage	20A
Input Plug Type	NEMA L6-20P
Rack Units	0U
Height	63.74 in (161.9 cm)
Depth	1.73 in (4.4 cm)
Material Compliance	RoHS Compliant, Lead Free, REACH SVHC Free
Country of Origin	India
