Schneider Electric NSYDLS48 Modular Distribution Chassis 540mm x 270mm for 48 Modules, Galvanized Steel
- MPN: NSYDLS48
- PPN: SCH-NSYDLS48
CAD
$190.45
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Designed for versatility and efficiency, this modular distribution chassis is an essential component for any multi-purpose electrical application. With a compact design measuring 540mm in height and 270mm in width, it accommodates up to 48 modules, making it ideal for complex installations. The chassis is constructed from galvanized steel, ensuring durability and resistance to environmental factors, while the self-extinguishing front panel adds an extra layer of safety. Its thoughtful design includes four horizontal rows and multiple cut-outs for easy access and installation, making it a reliable choice for professionals in the field. With a warranty of 18 months and compliance with various environmental standards, this chassis not only meets your operational needs but also aligns with modern sustainability practices.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Spain
- Width
- 9.84 in
Height20.47 in
Depth90 mm
Physical Attributes
- Color
- front panel Gray RAL 7032)
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB, SI
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Device Application
- modular distribution application, multi-purpose
- Enclosure Nominal Dimensions
- - H: 540 mm W: 270 mm D: 180 mm, - H: 540 mm W: 270 mm D: 180 mm, - H: 540 mm W: 270 mm D: 180 mm, - H: 540 mm W: 270 mm D: 180 mm, - H: 540 mm W: 270 mm D: 180 mm, - H: 540 mm W: 270 mm D: 180 mm, - H: 540 mm W: 270 mm D: 180 mm, - H: 540 mm W: 270 mm D: 180 mm
- Local Data Status
- Publishable
- Return Indicator
- N
- Stock Policy
- 2
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- With Recycled Cardboard
- No
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 2
- Function Option
- Standard
- Device Short Name
- DLS
- Mounting Location
- front of enclosure
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Range
- PanelSeT
- Sustainable Packaging
- No
- Type Of Front Plate
- cut-out plate
- Height Nominal
- 520 mm
- Width Nominal
- 250 mm
- Accessory / Separate Part Category
- mounting accessory
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market SegmentationCommercial, Industrial
Device Composition1 chassis structure, 1 front panel, 4 35 mm DIN rail
Materialfront panel self-extinguishing, chassis structure and rails galvanised steel
Local Publishable Date2026-04-14
Stocking FlagY
Weee ScopeOut
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeNo
Rohs Eur Conformity Date1916
China Rohs In ScopeNo
Without Single Use PlasticNo
Tier Id2
Function Option IdSTANDARD
Product Kit IdentifierN
Fixing Modeby fixing element - on front with supports
Number Of Horizontal Rows4
Product Or Component Typechassis
ReturnabilityNo
Total Number Of 18 Mm Modules48
Pep CodeENVPEP1107004EN
Height Useful520 mm
Width Real250 mm
Number Of Cut-out4 cut-outs
Package Weight(Lbs)1.378 kg
Warranty (In Months)18
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Recycled Metal Content At Cr Level
- 0 %
- Environmental Disclosure
- ENVPEP1107004EN
- Packaging Made With Recycled Cardboard
- No
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Take BackNo
Mercury FreeYes
Eu Rohs DirectiveCompliant By Exemption
Packaging Without Single Use PlasticNo
Pep CodeENVPEP1107004EN
General Attributes
- Product Or Component Type
- chassis
ETIM
- ETIM 8
- EC002625
ETIM 9EC002625
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
