Schneider Electric NSYDLS12 Modular Distribution Chassis 12 Modules, 180x270mm, Galvanized Steel
- MPN: NSYDLS12
- PPN: SCH-NSYDLS12
CAD
$122.15
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Designed to meet the demands of modular distribution applications, this chassis from Schneider Electric offers a robust solution for organizing and protecting electrical components. With a compact design that accommodates up to 12 modules, it features a self-extinguishing front panel and a galvanized steel structure, ensuring durability and safety. Measuring 255 mm in height, 170 mm in width, and 90 mm in depth, this chassis is specifically designed for front mounting within enclosures, making it an ideal choice for a variety of installations. Its compatibility with the Thalassa range further enhances its versatility, allowing for seamless integration into existing systems.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Spain
- Width
- 6.69 in
Height10.04 in
Depth90 mm
Physical Attributes
- Color
- front panel Gray RAL 7032)
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB, SI
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Device Application
- multi-purpose, modular distribution application
- Enclosure Nominal Dimensions
- - H: 180 mm W: 270 mm D: 180 mm, - H: 180 mm W: 270 mm D: 180 mm, - H: 180 mm W: 270 mm D: 180 mm, - H: 180 mm W: 270 mm D: 180 mm, - H: 180 mm W: 270 mm D: 180 mm, - H: 180 mm W: 270 mm D: 180 mm, - H: 180 mm W: 270 mm D: 180 mm, - H: 180 mm W: 270 mm D: 180 mm
- Local Data Status
- Publishable
- Return Indicator
- N
- Stock Policy
- 2
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- With Recycled Cardboard
- No
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 2
- Function Option
- Standard
- Device Short Name
- DLS
- Mounting Location
- front of enclosure
- Number Of Horizontal Rows
- 1
- Product Or Component Type
- chassis
- Returnability
- No
- Total Number Of 18 Mm Modules
- 12
- Accessory Separate Part Category
- mounting accessory
- Pep Code
- ENVPEP1107004EN
- Height Useful
- 255 mm
- Width Real
- 170 mm
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market SegmentationCommercial, Industrial
Device Composition1 chassis structure, 1 front panel, 1 35 mm DIN rail
Materialfront panel self-extinguishing, chassis structure and rails galvanised steel
Local Publishable Date2026-04-14
Stocking FlagY
Weee ScopeOut
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeNo
Rohs Eur Conformity Date1916
China Rohs In ScopeNo
Without Single Use PlasticNo
Tier Id2
Function Option IdSTANDARD
Product Kit IdentifierN
Fixing Modeby fixing element - on front with supports
Number Of Cut Out1 cut-out
Product AvailabilityNon-Stock - Not normally stocked in distribution facility
RangePanelSeT
Sustainable PackagingNo
Type Of Front Platecut-out plate
Warranty In Months18
Height Nominal255 mm
Width Nominal170 mm
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Recycled Metal Content At Cr Level
- 0 %
- Environmental Disclosure
- ENVPEP1107004EN
- Packaging Made With Recycled Cardboard
- No
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Take BackNo
Mercury FreeYes
Eu Rohs DirectiveCompliant By Exemption
Packaging Without Single Use PlasticNo
Pep CodeENVPEP1107004EN
General Attributes
- Product Or Component Type
- chassis
ETIM
- ETIM 8
- EC002625
ETIM 9EC002625
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
