Schneider Electric NSYDLS36 Modular Distribution Chassis 36 Modules 360mm x 270mm
- MPN: NSYDLS36
- PPN: SCH-NSYDLS36
CAD
$150.35
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Designed for versatility and efficiency, the modular distribution chassis from Schneider Electric is an essential component for any multi-purpose modular distribution application. With the capacity to accommodate up to 36 modules, this chassis features a robust construction with a self-extinguishing front panel and galvanized steel structure, ensuring durability and safety. Its compact dimensions of 360mm in height and 270mm in width make it suitable for various mounting locations, while the three cut-outs provide flexibility for installation. This product not only meets the demands of modern electrical systems but also aligns with environmental standards, making it a reliable choice for your distribution needs.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Spain
- Width
- 10.24 in
Height13.39 in
Depth90 mm
Physical Attributes
- Color
- front panel Gray RAL 7032)
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB, SI
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Device Application
- modular distribution application, multi-purpose
- Enclosure Nominal Dimensions
- - H: 360 mm W: 270 mm D: 180 mm, - H: 360 mm W: 270 mm D: 180 mm, - H: 360 mm W: 270 mm D: 180 mm, - H: 360 mm W: 270 mm D: 180 mm, - H: 360 mm W: 270 mm D: 180 mm, - H: 360 mm W: 270 mm D: 180 mm, - H: 360 mm W: 270 mm D: 180 mm, - H: 360 mm W: 270 mm D: 180 mm
- Local Data Status
- Publishable
- Return Indicator
- N
- Stock Policy
- 2
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- With Recycled Cardboard
- No
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 2
- Function Option
- Standard
- Device Short Name
- DLS
- Mounting Location
- front of enclosure
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Range
- PanelSeT
- Sustainable Packaging
- No
- Type Of Front Plate
- cut-out plate
- Height Nominal
- 340 mm
- Width Nominal
- 260 mm
- Accessory / Separate Part Category
- mounting accessory
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market SegmentationCommercial, Industrial
Device Composition1 chassis structure, 1 front panel, 3 35 mm DIN rail
Materialfront panel self-extinguishing, chassis structure and rails galvanised steel
Local Publishable Date2026-04-14
Stocking FlagY
Weee ScopeOut
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeNo
Rohs Eur Conformity Date1916
China Rohs In ScopeNo
Without Single Use PlasticNo
Tier Id2
Function Option IdSTANDARD
Product Kit IdentifierN
Fixing Modeby fixing element - on front with supports
Number Of Horizontal Rows3
Product Or Component Typechassis
ReturnabilityNo
Total Number Of 18 Mm Modules36
Pep CodeENVPEP1107004EN
Height Useful340 mm
Width Real260 mm
Number Of Cut-out3 cut-outs
Package Weight(Lbs)958.000 g
Warranty (In Months)18
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Recycled Metal Content At Cr Level
- 0 %
- Environmental Disclosure
- ENVPEP1107004EN
- Packaging Made With Recycled Cardboard
- No
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Take BackNo
Mercury FreeYes
Eu Rohs DirectiveCompliant By Exemption
Packaging Without Single Use PlasticNo
Pep CodeENVPEP1107004EN
General Attributes
- Product Or Component Type
- chassis
ETIM
- ETIM 8
- EC002625
ETIM 9EC002625
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
