Leviton G5262-WTG SmartlockPro GFCI Receptacle 15 Amp, Weather & Tamper-Resistant, Gray
- MPN: G5262-WTG
- UPC: 078477730904
- PPN: LEV-G5262-WTG
CAD
$67.95
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
SmartlockPro Self-Test GFCI Duplex Receptacle Outlet, Extra Heavy-Duty Industrial Specification Grade, Weather and Tamper-Resistant, Power Indication, 15 Amp, 20 Amp Feed-Through, 125 Volt, Back or Side Wire, NEMA 5-15R, 2-Pole, 3-Wire, Self-Grounding - Gray
Features
- Peace of mind, all the time. The SmartlockPro Self-Test GFCI tests itself even if you forget. Designed to meet the latest UL standard for auto-monitoring (self-test) our complete line of self-test GFCIs periodically conduct an automatic internal test to confirm that it can respond to a ground fault. With the slimmest profile on the market, the device allows for fast and easy installation, while Leviton’s patented reset lockout mechanism prevents reset of the GFCI if it is not wired or operating correctly. The SmartlockPro Self-Test GFCI is the smart choice in ground fault circuit interrupter protection.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | China |
|---|
| RoHS Compliant | False |
|---|
Standards and Certifications
| ANSI | C-73 |
|---|---|
| Certification/Listing | UL, CSA, NOM-ANCE |
| Applicable Standards | UL 943, UL 498, CSA C22.2 No. 42 & 144, FedSpec W-C-596 |
|---|---|
| NEMA | WD-1 & WD-6 |
Material Specifications
| Body Material | Polycarbonate |
|---|---|
| Ground Clips | Brass |
| Line Contacts | Brass |
| Strap Material | Nickel Plated Steel |
| Terminal Screws | Stainless Steel |
| Face Material | PBT |
|---|---|
| Grounding Screw | Stainless Steel |
| Shutter Mechanism | Delrin® Acetal |
| Terminal Clamp | Brass |
Mechanical Specifications
| Product ID | Ratings are permenantly marked on device |
|---|---|
| Terminal Accom. | 14-10 AWG solid or stranded |
| Termination | Back or Side Wire |
| Screw Terminal Torque | 14-18 in-lbs |
|---|---|
| Terminal ID | Black-Hot, White-Neutral, Green-Ground |
Product Features
| Brand | SmartlockPro |
|---|---|
| Device Type | Duplex Receptacle Outlet |
| Function | GFCI |
| Color | Gray |
|---|---|
| Feature | Weather and Tamper-Resistant|Power Indication |
| Grade | Extra Heavy-Duty Industrial Specification Grade |
Warranty
| Warranty | 2-Year Limited |
|---|
Environmental Specifications
| Flammability | Rated V-0 per UL 94 |
|---|
| Operating Temperature | -35C to +66C |
|---|
Electrical Specifications
| Amperage | 15 A & 20 A Feed-Through |
|---|---|
| Pole | 2 |
| Voltage | 125 VAC |
| Grounding | Self-Grounding |
|---|---|
| Short Circuit Current Rating | 10kA |
| Wire | 3 |
AC Horsepower Ratings
| At Rated Voltage | 1 HP |
|---|
