SolaHD A2D120HW 3000VA Single Phase Industrial On-Line UPS, 120V, 2U Rack-Mount
- MPN: A2D120HW
- PPN: SHD-A2D120HW
CAD
$2026.55
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
S4K2U-C and S4K2U-5C Industrial On-Line UPSs are single phase, online (double conversion) UPS available in 500-3000VA, 120V and 230V. Online design means zero transfer time from external to internal power, so when utility power fails, your critical load remains supported by a seamless flow of power. Housed in a slim 2U package, the rack or tower configurable S4K2UC offers a higher power factor, longer battery life, higher reliability and reduced cost of ownership.
Features
- cULus, CE, Federal Comminucations Commission
- Hardwire capability for permanent installation
- Small 2U height maximizes available space. Rack-mount or stand-alone tower mounting
- Input and output noise suppression
- Higher output power factor of 0.90
- PWM inverter reduces output voltage distortion
- Hot swappable user replaceable battery (integral sealed non-spillable). Add on batteries for extended back-ups
- Automatic restart. Automatic and manual battery test
- Units are field configurable with a PC as a frequency converter (bypass will be disabled)
Documentation & Downloads
Specifications
Additional
- Capacity
- 700-3000 VA / 630-2700 W
- Phase
- Single Phase
- Input Voltage Range
- 60-140 Vac
- Typical Back-up Time at 120 Vac (minutes, full/half load)
- 700/630: 11/27; 1000/900: 7/17; 1500/1350: 4/11; 2000/1800: 3/11; 3000/2700: 3/11
- Height
- 2U (3.5 in)
- Weight
- 16.8 to 32.4 kg (37.0 to 71.4 lbs) depending on model
- Battery Configuration
- 4 x 12 V x 5.0-9.0 Ah or 6 x 12 V x 9.0 Ah
- Operating Temperature
- 0 C to +40 C (+32 F to +104 F)
Voltage120 Vac, 230 Vac
Output Voltage Range110/115/120/127 Vac (user-configurable) 3%
Frequency50/60 Hz
Typical Back-up Time at 230 Vac (minutes, full/half load)1000/900: 6/17; 2000/1800: 3/11; 3000/2700: 3/11
Dimensions (D x W x H)500.4 x 430.0 x 86.4 mm (19.70 x 16.90 x 3.40 in) or 602.0 x 430.0 x 86.4 mm (23.70 x 16.90 x 3.40 in)
Battery TypeValve-regulated, non-spillable, lead acid
Battery Recharge Time3 hours to 90% after full discharge
