Schneider Electric NSYTRR42BL Linergy TR Terminal Block, 4 mm², Blue, Set of 50, 600 V Rated
- MPN: NSYTRR42BL
- PPN: SCH-NSYTRR42BL
CAD
$3.35
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The Schneider Electric NSYTRR42BL Linergy TR Terminal Block is a reliable solution for connecting electrical circuits, offering efficient performance in automation and control applications. Each block in this set of 50 is designed to accommodate conductor sizes of 4 mm² and is rated for 600 V, ensuring safety and functionality in a wide range of installations. With a striking blue color, these terminal blocks provide not only practicality but also enhanced visibility during setups and troubleshooting, making them ideal for professionals and technicians in need of dependable connections in their projects.
Documentation & Downloads
Specifications
Additional
- Rated Operational Voltage
- 600 V CSA, 800 V EN/IEC 60947-7-1, 600 V cURus
- Number of Connections
- 2
- Cable Cross Section Range
- 0.08-4 mm² solid without cable end, 0.08-4 mm² flexible without cable end, 0.08-6 mm² solid with cable end, 0.2-4 mm² flexible with cable end
- Connection Type
- 1 x spring terminal upstream, 1 x spring terminal downstream
- Width
- 6.2 mm (0.24 in)
- Terminal Block Type
- Passthrough
- Material
- Polyamide 6/6 (insulating case), Copper alloy (connector, screw, commoning link), Chromium-nickel steel (spring)
- Resistivity
- 10000 MΩ·m IEC 60093
- Creep Resistance
- 500 CTI (> 400 kB) IEC 60093
- Dielectric Strength
- 1000 V IEC 60243-1
- Compliance
- EAC, VDE, IECEx, GL, CSA, LR, ATEX, DNV, cURus
- Country of Origin
- Germany
Line Rated Current32 A EN/IEC 60947-7-1, 30 A CSA, 30 A cURus
Nominal Cross Section4 mm²
Ambient Temperature Range-40 to 130 °C IEC 60216-1
Length56 mm (2.20 in)
Height36.5 mm (1.44 in)
Wire Stripping Length10 mm (0.39 in)
Dielectric Constant3.7 at 1 MHz
Surface Resistance1000 GΩ IEC 60093
Flame RetardanceV0 0.8 mm UL 94
Tool TypeFlat screwdriver for connection and disconnection
ColorBlue
