Hubbell Wiring Device-Kellems HBL5236 15A 125V Brown Phenolic Flush Plug, 2-Pole 3-Wire, 4.5 Inch x 2.75 Inch x 1.8 Inch
- MPN: HBL5236
- UPC: 783585013787
- PPN: HBL-HBL5236
- UNSPSC: 39121406
CAD
$213.57
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Straight Blade Miscellaneous Display type, brown phenolic,blank flush plug, 15A 125V, 2-Pole 3-Wire Grounding, 5-15R
Features
- Miscellaneous Receptacles
- Display type
- brown phenolic
- blank flush plug
- Display Case Receptacle
Specifications
Key Specifications
- Engineering Drawing 1 Display Text
- HBL5236 AutoCAD Drawing
- Current / Amperage Rating
- 15 A
- Height
- 1.8 in
- Industry Standard(s)
- Certified to CSA, C22.2, No. 42 File 285;NEMA® WD-6 Compliant;UL Listed to UL498 File E2186
- Performance
- Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V-2 or better;Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #14-#10 AWG copper stranded or solid conductor only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
- Application
- Commercial Specification Grade
- Dielectric Strength
- Withstands 2,000V minimum
- NEMA Rating
- 5-15R
- Number of Wires
- 3-Wire
- Size
- 4.5 in x 2.75 in x 1.8 in
- Standard
- Certified to CSA, C22.2, No. 42 File 285;NEMA® WD-6 Compliant;UL Listed to UL498 File E2186
- Wattage
- 1875 W
- Voltage Rating Description
- 125 V
- Width
- 2.75 in
- Display Size
- Standard Sized Product
- Number Of Poles
- 2-Pole
- Operating Temperature
- Maximum continuous 75°C and minimum -40°C without Impact
- Description - Invoice
- DISPLAY RCPT, 15A 125V, NEMA 5-15R
- Harmonization Code
- 8536690200
- MSDS Flag
- No
- Sub Class Code
- A04A020
- Current Rating
- 15 A
- BOX SIZE
- 5.300x11.000x6.700 (in)
- Carton - Number of Sub Packs
- 10
- Carton - SCC-14 Next Lower Level Sub Pack
- 783585013787
- Case - Total Units
- 20 EA
- Each - Pack Description
- Each
- NAICS Code
- 335931A102
Country of OriginChina
Dimensions4.5 in x 2.75 in x 1.8 in
Horsepower - Maximum0.5
Length4.5 in
Amperage Rating15 A
ColorBrass
Environmental ConditionsIndoor Dry Unless Protected By Additional Means
Number of Poles2-Pole
PhaseSingle Phase
Special FeaturesDisplay Case Receptacle
Voltage Rating125 V
Wire Size#14 AWG to #10 AWG
Weight0.55 lb.
ConnectivityScrew Terminals
Nema Rating5-15R
Number Of Wires3-Wire
Class CodeA04
Freight Class Code06168002
Image Actual Or RepresentativeA
Replaced Catalog Number5236
Material - Mounting HardwareScrew Mounting
Base Unit of MeasureEA
Carton - Gross Weight per Pack5.500 lb.
Carton - Pack DescriptionCarton
Carton - Total Units10 EA
Case Weight5.650 lb.
Lowest Level UOMEach
