Square D 9080FB1611M Terminal Block Fuse Holder, 30A, 600V, 1 Pole, Thermoplastic, 3.13 Inch Height
Square D 9080FB1611M Terminal Block Fuse Holder, 30A, 600V, 1 Pole, Thermoplastic, 3.13 Inch Height
- MPN: 9080FB1611M
- UPC: 785901091462
- PPN: SCH-9080FB1611M
- UNSPSC: 39121624
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$17.35/ EA
Description
Type S non-reversing magnetic starters are for motor control applications. NEMA Size 1 starters have ratings of 7.5 HP at 200 and 230 VAC and 10 HP at 460 and 575 VAC poly phase and has a maximum rating of 27 Amps. This 3 pole starter is for poly phase applications. These starters are available with a wide variety of replaceable coil voltages. Starter has a 208 VAC 60 Hz operating coil. The melting alloy type overload relay uses Type B thermal units to sense over current conditions. A painted sheet steel NEMA 12/3R dust tight and drip tight enclosure is used to protect this starter. Enclosure is 12.75 inches tall, 6.38 inches wide and 8.53 inches deep. A wide variety of accessories are available for Type S starters. Type S starters are UL listed and CSA certified for global applications.
Features
- This one pole fuse holder will accept class M fuses
- The rating of the fuse can be up to 30 Amps with a 600 V maximum rating
- The fuse holder base is made of high impact thermoplastic
- This fuse holder is UL listed and CSA certified
Specifications
Physical Attributes
- Fuse Size
- 0.4063 x 1.5 in
Wire Stripping Length0.4375 in
Conformance Attributes
- Product Certifications
- CE, UL recognized E40747 CCN IZLT2, CSA file 70360 class 6225 01
Complementary Attributes
- Line Rated Current
- 30 A
Important Information Attributes
- Persona Type Ids
- LC, OM8, PB
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Ue Rated Operational Voltage2
- <= 600 V AC/DC, <= 600 V AC/DC
- Local Data Status
- Publishable
- Device Type
- LV equipment - LV fuse - disconnector
- Traceability
- No
- Scope Perimeter
- Outside of Europe
- Reach Full Compliance Status Id
- NOT_CONTAINING_SVHC
- ROHS EUR In Scope
- Yes
- ROHS EUR Full Compliance Status
- Compliant
- China ROHS In Scope
- No
- Without Single Use Plastic
- No
- Return Indicator
- Y
- Function Option
- Standard
- Electrical Connection
- pressure wire clamp
- Fuse Type
- M
- Mounting Support
- surface mount
- Product Availability
- Stock - Normally stocked in distribution facility
- Range Of Product
- 9080FB
- Sustainable Packaging
- No
- Connections Terminals
- screw terminals 25 lbf.in AWG 14...AWG 10 copper
- Stocking Flag
- N
- Global Commercial Status
- Commercialised
- Ics Rated Service Breaking Capacity5
- 100 kA UL 512
Persona Type NamesContractor, OEM - Control Panelbuilder, Panel Builder
Market SegmentationCommercial, Industrial
Ue Rated Operational Voltage5<= 600 V AC/DC, <= 600 V AC/DC
Local Publishable Date2025-11-13
ServiceabilityNo
Legacy WEEE ScopeIn
Reach Full Compliance StatusFree of Substances of Very High Concern above the threshold
Reach Compliance DirectiveFree of Substances of Very High Concern above the threshold
ROHS EUR StatusCompliant
ROHS EUR Full Compliance Status IdCOMPLIANT
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
Function Option IdSTANDARD
AWG GaugeAWG 14...AWG 10 copper or aluminium
Energy Efficiency OptimizedFalse
Materialthermoplastic: block
Package Weight Lbs40.823 g
Product Or Component Typefuse holder
ReturnabilityYes
Ics Rated Service Breaking Capacity2100 kA UL 512
Medium DescTerminal block, Linergy, fuse holder, Class M, 30A, 600V, 1 pole
Product Kit IdentifierN
Connections Terminals3screw terminals 25 lbf.in AWG 14...AWG 10 copper
Environment Attributes Main
- China ROHS Regulation
- Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
- ROHS Exemption Information
- Yes
- Reach Free SHVC
- Yes
- Toxic Heavy Metal Free
- Yes
- Ambient Air Temperature For Operation
- -40-257 °F
- Packaging Without Single Use Plastic
- No
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
EU ROHS DirectiveCompliant , Compliant
Take BackNo
Recycled Metal Content At Cr Level0 %
Mercury FreeYes
Packaging Made With Recycled CardboardYes
Reach Free Of SVHCYes
General Attributes
- Product Or Component Type
- fuse holder
Range Of Product9080FB
