Schneider Electric GV4AU247 Undervoltage release, TeSys GV4, MN coil, 220 to 240VAC 50Hz 208 to 240VAC 60Hz
- MPN: GV4AU247
- PPN: SCH-GV4AU247
CAD
$224.20
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
TeSys GV electrical trip unit, MN undervoltage release, 208-240V AC 50/60Hz, for motor circuit breakers GV4. Opening of the the circuit breaker is ensured when the control voltage drops below 0.35 Uc, and possible between 0.35-0.7 Uc. Closing of the circuit breaker is possible when the control voltage is in limits 0.85-1.1 Uc. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA).
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Brazil, France, Poland, Sweden
Physical Attributes
- Wire Stripping Length
- 8 mm
Complementary Attributes
- Maximum Inrush Power In Va
- 7 VA
Important Information Attributes
- Operating Time
- < 50 ms, < 50 ms
- Carbon Footprint Of The Distribution Phase [A4]
- 0.008369066666666666, 0 kg CO2 eq.
- Carbon Footprint Of The Installation Phase [A5]
- 0.02840533333333333, 0 kg CO2 eq.
- Carbon Footprint Of The Use Phase [B2 B3 B4 B6]
- 251 kg CO2 eq., 251.33
- Local Publishable Date
- 2025-02-26
- Stocking Flag
- Y
- Serviceability
- No
- Field Service Division
- PPIBS
- Use Carbon Footprint
- 251.33
- Weee Scope
- In
- Scope Perimeter
- At least in Europe
- End Of Life Doc Ref
- ENVEOLI2311042EN
- Reach Full Compliance Status Id
- CONTAINS_SVHC
- Rohs Eur In Scope
- Yes
- Rohs Eur Conformity Date
- 1824
- China Rohs In Scope
- No
- With Recycled Cardboard
- Yes
- Product Contributes To Saved And Avoided Emissions
- No
- Device Application
- control
- Energy Efficiency Optimized
- False
- Mechanical Durability
- 20000 cycles
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Quantity Per Set
- set of 1
- Returnability
- No
- Sustainable Packaging
- Yes
- Voltage Release Type
- undervoltage release
- Pep Code
- ENVPEP2311042EN
- Pep Verification Date
- 2023-12-03
- Psr Version
- PSR-0005-ed2-2016 03 29
- Data Source
- extrapolated product
- Functional-unit Quantity
- 1
- Reference Lifetime In Y
- 10
- Energy Model - Manufacturing [A1-a3]
- Electricity Mix; Production mix; Low voltage; FR
- Energy Model - Use [B6]
- Electricity Mix; Production mix; Low voltage; UE-27
- Recyclability Potential In %
- 32
- [Ui] Rated Insulation Voltage
- 240 V IEC 60947-1
- Maximum Hold-in Power Consumption In Va
- 7 VA
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
- Acidification (Ap) (Mole Of H+ Equiv) Operational Energy Use [B6]
- 1.4341
- Climate Change - Fossil Fuels ( Kg Co2 Eq.) End Of Life [C1-c4]
- 0.1048
- Climate Change - Total ( Kg Co2 Eq.) Operational Energy Use [B6]
- 251.33
- Ecotoxicity (Fresh Water) (Ctue) Operational Energy Use [B6]
- 2706.6
- Ionizing Radiation Human Health (Kbq Of U235 Equiv.) Operational Energy Use [B6]
- 373.69
- Non-hazardous Waste Disposed Of (Kg) Operational Energy Use [B6]
- 36.161
- Total Use Of Primary Energy During The Life Cycle (Mj) Manufacturing [A1-a3]
- 11.592
- Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6]
- 1229.6
- Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]
- 1229.6
- Customs Code
- 8536308000
Threshold Tripping Voltage< 0.35 Un failsafe opening, < 0.35 Un failsafe opening< 0.35 Un failsafe opening, < 0.35 Un failsafe opening0.35...0.7 Un possible opening0.85...1.1 Un enabled closing
Carbon Footprint Of The End-of-life Phase [C1 To C4]0.1 kg CO2 eq., 0.10678222222222222
Carbon Footprint Of The Manufacturing Phase [A1 To A3]0.7 kg CO2 eq., 0.73
Local Data StatusPublishable
Return IndicatorN
Stock Policy2
TraceabilityNo
Manufacturing Carbon Footprint0.73
Weee ApplicabilityFinished product
Weee Product Category5
Eoli Availability DisplayYes
Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
Rohs Eur StatusCompliant By Exemption
Rohs Eur Full Compliance StatusCompliant By Exemption
China Rohs Label7
Without Single Use PlasticYes
Product Kit IdentifierN
Device Short NameMN
Maximum Inrush Power In Va7 VA
Mounting Modeinternal mounting
Product Or Component Typevoltage release
RangeTeSys
Software Versionv5.9.4
Total Lifecycle Carbon Footprint252 kg CO2 eq.
Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Database Version2022-01
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent external review
Functional-unit DescriptionTo trip the circuit breaker when the control voltage drops below 35% of its rated voltage.& 10Between 35% and 70% of the rated voltage opening is possible but not ensured.& 10This function is provided for 10 years.& 10It complies with IEC 60947-2 standard.
Functional-unit UnitUnit
Energy Consumption On Product Lifetime In Kwh613.2
Energy Model - Installation [A5]Electricity Mix; Production mix; Low voltage; UE-27
Energy Model - End Of Life [C1-c4]Electricity Mix; Production mix; Low voltage; UE-27
[Uc] Control Circuit Voltage220...240 V AC 50 Hz208...240 V AC 60 Hz
Connections - Terminalsspring terminals 1 0.5-1.5 mm² - cable stiffness: flexible without cable end
Halogen-free StatusProduct contains halogen above thresholds
Package Weight(Lbs)64.0 g
Warranty (In Months)18
Climate Change - Fossil Fuels ( Kg Co2 Eq.) Operational Energy Use [B6]251
Climate Change - Total ( Kg Co2 Eq.) Manufacturing [A1-a3]0.73
Depletion Of Abiotic Resources - Fossil Fuels (Mj) Operational Energy Use [B6]6403.1
Impacts Related To Land Use/Soil Quality (-) Operational Energy Use [B6]5.0007
Non-hazardous Waste Disposed Of (Kg) Installation [A5]0.0924
Terrestrial Eutrophication (Mole Of N Equiv) Operational Energy Use [B6]2.4482
Total Use Of Primary Energy During The Life Cycle (Mj) Operational Energy Use [B6]7632.7
Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]6403.1
Water Use (M3 Eq) Operational Energy Use [B6]8.8931
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Halogene Performance
- Product contains halogen above thresholds
- Mercury Free
- Yes
- Circularity Profile
- ENVEOLI2311042EN
- Eu Rohs Directive
- Compliant By Exemption
- Packaging Made With Recycled Cardboard
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Pep Verification Date
- 2023-12-03
- Psr Version
- PSR-0005-ed2-2016 03 29
Take BackNo
Recycled Metal Content At Cr Level0 %
Carbon Footprint252.20355662222224
Environmental DisclosureENVPEP2311042EN
Halogen Content PerformanceProduct contains halogen above thresholds
Packaging Without Single Use PlasticYes
Pep CodeENVPEP2311042EN
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent external review
General Attributes
- Product Or Component Type
- voltage release
ETIM
- ETIM 8
- EC001022
ETIM 9EC001022
