Schneider Electric CA2KN40T7 TeSys K Control Relay, 4NO, 480V AC Coil, 690V Rated Voltage
Schneider Electric CA2KN40T7 TeSys K Control Relay, 4NO, 480V AC Coil, 690V Rated Voltage
- MPN: CA2KN40T7
- PPN: SCH-CA2KN40T7
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$120.88/ EA
Description
The TeSys K Control Relay from Schneider Electric is an essential component for automation and control applications, featuring a robust design tailored for reliable performance. This model, with four normally open (NO) contacts, operates at a 480V AC coil voltage, making it suitable for a variety of industrial settings. With a rated current of 10 A, the relay ensures efficient switching and control of electrical circuits, contributing to enhanced operational safety and reliability. Its integration into IEC control systems makes it a versatile choice for panel builders and engineers looking to optimize their electronic control configurations.
Specifications
- Rated Operational Voltage
- <= 690 V <= 400 Hz
- Conventional Thermal Current
- 10 A (at 50 °C)
- Associated Fuse Rating
- 10 A gG IEC 60947, 10 A gG VDE 0660
- Hold-in Power Consumption
- 4.5 VA (at 20 °C)
- Operating Time
- 10-20 ms coil de-energisation and NO opening, 10-20 ms coil energisation and NO closing
- Immunity to Microbreaks
- 2 ms
- Minimum Switching Current
- 5 mA
- Non Overlap Distance
- 0.5 mm
- Dimensions (HxWxD)
- 58 mm x 45 mm x 57 mm (2.28 in x 1.77 in x 2.24 in)
- Mounting
- Rail, Plate
- Contact Composition
- 4 NO
- Mechanical Robustness
- Vibrations open 2 Gn 5-300 Hz, closed 4 Gn 5-300 Hz; Shocks open 10 Gn 11 ms, closed 15 Gn 11 ms IEC 60068
- IP Degree of Protection
- IP2X
- Ambient Air Temperature for Storage
- -50 to 80 °C (-58 to 176 °F)
- Standards
- EN/IEC 60947-4-1, GB/T 14048.4, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1
- Eu Rohs Directive
- Compliant
- Mercury Free
- Yes
Control Circuit Voltage480 V AC 50/60 Hz
Irms Rated Making Capacity110 A IEC 60947
Rated Insulation Voltage690 V IEC 60947, 750 V VDE 0110 group C, 690 V BS 5424, 600 V CSA C22.2 No 14
Inrush Power30 VA (at 20 °C)
Maximum Operating Rate10000 cyc/h
Minimum Switching Voltage17 V
Mechanical Durability10 Mcycles
Tightening Torque1.3 N.m screw clamp terminals
Net Weight0.18 kg (0.40 lb)
Terminal Connection TypeScrew clamp terminals 1.5-4 mm² solid & 0.75-4 mm² flexible
MaterialFlame Retardant V1 UL 94
Protective TreatmentTC IEC 60068
Ambient Air Temperature for Operation-25 to 50 °C (-13 to 122 °F)
Operating Altitude2000 m (6562 ft) without derating
CertificationsCB, CCC, UL, CSA, EAC, CE, UKCA
Reach Free Of SvhcYes
Toxic Heavy Metal FreeYes
