Schneider Electric CA2KN31M7 TeSys K Control Relay, 4P (3NO+1NC), 220-230V AC, 10A, 45mm Width

MPN: CA2KN31M7
PPN: SCH-CA2KN31M7

$128.12

Available to Order

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys K control relay, 4 contacts (3NO + 1NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 220-230V 50/60Hz AC control circuit, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC).

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Brazil, France, Indonesia

Depth	57 mm

Complementary Attributes

Control Circuit Type	AC 50/60 Hz
Irms Rated Making Capacity	110 A IEC 60947
Minimum Switching Current	5 mA

Control Circuit Voltage Limits	drop-out: 0.2...0.75 Uc (at <50 °C)operational: 0.8...1.15 Uc (at <50 °C)
Maximum Operating Rate	10000 cyc/h
Minimum Switching Voltage	17 V

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SI
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Associated Fuse Rating	10 A gG conforming to IEC 60947, 10 A gG conforming to VDE 0660
Mechanical Robustness	vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6, shocks contactor open10 Gn for 11 ms IEC 60068-2-27, shocks contactor closed15 Gn for 11 ms IEC 60068-2-27
Operating Time	10...20 ms coil de-energisation and NO opening, 10...20 ms coil energisation and NO closing15...25 ms coil de-energisation and NC closing5...15 ms coil energisation and NC opening
Utilisation Category	AC-15, DC-13
[Ue] Rated Operational Voltage	<= 690 V <= 400 Hz, <= 690 V <= 400 Hz<= 690 V <= 400 Hz, <= 690 V <= 400 Hz
Connections - Terminals	screw clamp terminals 2 0.34-1.5 mm²flexible without cable end, screw clamp terminals 1 1.5-4 mm²solid, screw clamp terminals 2 1.5-4 mm²solid, screw clamp terminals 1 0.75-4 mm²flexible with cable end, screw clamp terminals 2 0.75-4 mm²flexible without cable end, screw clamp terminals 1 0.34-1.5 mm²flexible with cable end
Carbon Footprint Of The End-of-life Phase [C1 To C4]	0.3 kg CO2 eq., 0.2547335499948574
Carbon Footprint Of The Manufacturing Phase [A1 To A3]	0.9 kg CO2 eq., 0.9088802050732269
Local Data Status	Publishable
Return Indicator	N
Stock Policy	1
Serviceability	No
Weee Scope	In
Scope Perimeter	At least in Europe
End Of Life Doc Ref	ENVEOLI1503003
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	2448
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Contactor Application	control circuit
Heat Dissipation	1.3-1.3 W
Inrush Power In Va	30-30 VA (at 20 °C)
Mechanical Durability	10 Mcycles
Pole Contact Composition	3 NO + 1 NC
Product Name	TeSys CAK
Protective Treatment	TC IEC 60068
Range Of Product	TeSys K control relay
Software Version	v6.2.4
Total Lifecycle Carbon Footprint	72 kg CO2 eq.
Pole Contact Comp	3 NO + 1 NC
Control Circuit Voltage 21 Control Circuit Voltage	220...230 V
Pep Code	ENVPEP1503003EN
Pep Verification Date	2026-03-23
Psr Version	PSR-0005-ed3-2023 06 06
Data Source	extrapolated product
Functional-unit Quantity	1
Reference Lifetime In Y	20
Energy Model - Manufacturing [A1-a3]	Electricity Mix; Low voltage; 2020; France, FR
Energy Model - Use [B6]	Electricity Mix; Low voltage; 2020; Europe, EU-27
Recyclability Potential In %	63
Width Nominal	45 mm
[Uc] Control Circuit Voltage	220...230 V AC 50/60 Hz
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8536490075

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market Segmentation	Commercial, Industrial
Flame Retardance	V1 conforming to UL 94requirement 2 conforming to NF F 16-101, requirement 2 conforming to NF F 16-102
Mounting Support	plate, rail
Tightening Torque	1.3 N.m screw clamp terminals flat Ø 6 mm1.3 N.m screw clamp terminals Philips No 2 6 mm, 1.3 N.m screw clamp terminals pozidriv No 2
Certificate Agency	CB Scheme, CCC, UL, CSA, EAC, CE, UKCA
[Ui] Rated Insulation Voltage	690 V IEC 60947750 V VDE 0110 group C, 690 V BS 5424600 V CSA C22.2 No 14
Carbon Footprint Of The Distribution Phase [A4]	0.35078099527490714, 0.4 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]	0.024114736663035877, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]	71 kg CO2 eq., 70.81551905511422
Local Publishable Date	2026-06-27
Stocking Flag	Y
Device Type	LV equipment - LV contactor
Traceability	No
Weee Product Category	5
Eoli Availability Display	Yes
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Compatibility Code	CA2K
Device Short Name	CA2K
Immunity To Microbreaks	2 ms
Insulation Resistance	> 10 MOhm> 10 MOhm
Non Overlap Distance	0.5 mm
Product Availability	Non-Stock - Not normally stocked in distribution facility
Product Or Component Type	control relay
Range	TeSys
Returnability	No
Sustainable Packaging	Yes
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Control Circuit Voltage 21	220...230 V
Connections Terminals 55 Connections Terminals	screw clamp terminals
Database Version	2024-01
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
Functional-unit Description	Establish and cut off the supply of a downstream installation from an electrical and/or mechanical control characterised by the composition of the poles or type of contacts X, a rated voltage of Ue, a rated current Ie, a control circuit voltage Uc, with Np poles, and if applicable the specific specifications, in the Household/Commercial or Industrial application areas, according to the appropriate use scenario, and during the reference service life of the product of 20 years
Functional-unit Unit	unit
Energy Consumption On Product Lifetime In Kwh	175.2
Energy Model - Installation [A5]	No energy used
Energy Model - End Of Life [C1-c4]	Global, European and French datasets are used.
Height Nominal	58 mm
[Ith] Conventional Free Air Thermal Current	10 A (at 50 °C)
Hold-in Power Consumption In Va	4.5-4.5 VA (at 20 °C)
Package Weight(Lbs)	177.000 g
Warranty (In Months)	18

Environment Attributes Main

Ambient Air Temperature For Operation	-25-50 °C, -25-50 °C
Take Back	No
Recycled Metal Content At Cr Level	0 %
Toxic Heavy Metal Free	Yes
Carbon Footprint	72.35402854212025
Environmental Disclosure	ENVPEP1503003EN
Ip Degree Of Protection	IP2X
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP1503003EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review

Ambient Air Temperature For Storage	-50-80 °C, -50-80 °C
Reach Free Shvc	Yes
China Rohs Regulation	X
Mercury Free	Yes
Circularity Profile	ENVEOLI1503003
Eu Rohs Directive	Compliant
Operating Altitude	6561.68 ft (2000 m) without derating
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2026-03-23
Psr Version	PSR-0005-ed3-2023 06 06
