Bryant RR15LA Straight Blade Receptacle Duplex 15A 125V, 2-Pole 3-Wire Grounding, Push Terminals
- MPN: RR15LA
- UPC: 883778119231
- PPN: HBL-RR15LA
- UNSPSC: 39121406
CAD
$2.15
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
tradeSELECT® Straight Blade Receptacle, Residential Grade, Duplex, 15A125V, 2-Pole 3-Wire Grounding, 5-15R, Push Terminals
Features
- Smooth indented face appearance
- Multiple-drive Slot/Phillips/Robertson head screws
- Tough thermoplastic ultrasonically welded cover and base
- Self Grounding
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- China
- Width
- 1.560 in
- Amperage Rating
- 15 A
- Color
- Light Almond
- NEMA Rating
- 5-15R
- Number of Wires
- 3-Wire Grounding
- Special Features
- Self Grounding
- Wattage
- 1875
- Voltage Rating Description
- 125 VAC
- Display Size
- Standard Sized Product
- Number Of Poles
- 2-Pole
- Description - Invoice
- RESI DUP RCPT, 15A 125V, PUSH TERM, LA
- Harmonization Code
- 8536698000
- MSDS Flag
- No
- Material - Mounting Hardware
- Screw Mounting
- Material
- Thermoplastic
- BOX SIZE
- 1.900x8.000x4.300 (in)
- Carton - Number of Sub Packs
- 10
- Carton - SCC-14 Next Lower Level Sub Pack
- 883778119231
- Case - Total Units
- 200 EA
- Each - Pack Description
- Each
- Pallet - GTIN - Package
- 70883778119230
- Pallet Length
- 48.000 in
- Pallet Width
- 40.000 in
Current / Amperage Rating15 A
PerformanceEnvironmental - Operating temperature - -20°C to 60°C;Mechanical - Terminal - Terminal screws accepts up to #12 AWG, Push wire designed for #14 AWG solid copper wire only
ApplicationResidential Receptacles
Environmental ConditionsIndoor Dry Unless Protected By Additional Means
Number of Poles2-Pole
PhaseSingle Phase
Voltage Rating125 VAC
Wire Size#14 AWG to #12 AWG
ConnectivityPush and Side Wire
Nema Rating5-15R
Number Of Wires3-Wire Grounding
Freight Class Code06168002
Image Actual Or RepresentativeA
Replaced Catalog NumberRR15AL
Current Rating15 A
Base Unit of MeasureEA
Carton - Gross Weight per Pack1.200 lb.
Carton - Pack DescriptionCarton
Carton - Total Units10 EA
Case Weight26.200 lb.
Lowest Level UOMEach
Pallet Height42.500 in
Pallet Weight1310.000 lb.
Certifications
- EU RoHS Indicator
- Yes
