Tripp Lite U244-001-VGA USB 2.0 to VGA Multi-Monitor Adapter, 1080p @ 60 Hz, 128 MB SDRAM
- MPN: U244-001-VGA
- UPC: 037332196514
- PPN: TRP-U244-001-VGA
CAD
$54.43
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Connect a VGA monitor or projector to the USB 2.0 port of your computer or laptop. Use up to 6 adapters to connect up to 6 additional displays to a source. Ideal for multitasking, presentations and editing documents.
Features
- Supports HD video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
- Extend video to a second display or duplicate one video on both
- Add up to 6 adapters to connect a total of 7 displays (Windows)
- Plug and play—no external power supply needed
- Compatible with Windows®, Mac® and Ubuntu
- 3-year limited warranty
Documentation & Downloads
Specifications
Features & Specifications
| Max Supported Video Resolution | 1920 x 1080 (1080p) @ 60 Hz |
|---|---|
| Driver Required | Yes |
| USB Specification | USB 2.0 (up to 480 Mbps) |
|---|---|
| Technology | USB 2.0 (High Speed); USB; VGA/SVGA |
Certifications
| Certifications | Tested to CE, FCC, RoHS, REACH |
|---|
Connections
| Side A - Connector 1 | USB A (MALE) |
|---|---|
| Connector Plating | Nickel |
| Side B - Connector 1 | HD15 (FEMALE) |
|---|
Physical
| Cable Jacket Rating | VW-1 |
|---|---|
| Material of Construction | ABS, PVC |
| Shipping Weight (lbs.) | 0.40 |
| Unit Packaging Type | Box |
| Color | Black |
|---|---|
| Shipping Dimensions (hwd / in.) | 0.90 x 5.10 x 5.50 |
| Unit Dimensions (hwd / in.) | 0.6 x 1.7 x 1.8 |
| Unit Weight (lbs.) | 0.3 |
Input
| Bus Powered | Yes |
|---|
| Product Length (in.) | 7 |
|---|
Environmental
| Operating Temperature Range | 32 to 104 F (0 to 40 C) |
|---|---|
| Relative Humidity | 10% to 90 % RH, Non-Condensing |
| Power Consumption (Watts) | 1.3 |
| Storage Temperature Range | -4 to 140 F (-20 to 60 C) |
|---|---|
| BTUs | 4.4 BTU/Hr |
Overview
| UPC Code | 037332196514 |
|---|
Warranty
| Product Warranty Period (Worldwide) | 3-year limited warranty |
|---|
