Tripp Lite U444-06N-HGUB-C USB-C Multiport Adapter, 4 Ports, 60W PD Charging, HDMI 1080p
- MPN: U444-06N-HGUB-C
- UPC: 037332209160
- PPN: TRP-U444-06N-HGUB-C
CAD
$122.13
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Adds HDMI, USB-A, USB-C PD charging and Gigabit Ethernet ports to your tablet, laptop, notebook, smartphone or PC.
Features
- Transmits DisplayPort signals from sources supporting USB DisplayPort Alt Mode
- Delivers HD picture quality at resolutions up to 1920 x 1080 (1080p) @60 Hz
- BC 1.2-compliant USB-A port provides up to 1.5A of fast-charging power
- Connects you to a wired Ethernet network when no Wi-Fi is available
- Powers and charges PD Charging-compliant devices, such as MacBooks and Chromebooks
- Easy installation with plug-and-play operation—no software required
- 3-year limited warranty
- Mini Docking Station Turns Your Device’s USB-C or Thunderbolt 3 Port into a Multiport Workstation
- Supports USB DisplayPort Alternate Mode for Transmitting Audio/Video DisplayPort and USB Signals
- Transmits Crystal-Clear 1080p Video and Digital Audio to an HDMI Display
- Connects a USB Peripheral
- Charges a Connected Device
- Accesses a Wired Gigabit Ethernet Network
- Built-In USB-C Cable Connects in Either Direction
- Ready to Use Right Out of the Package
- 3-Year Warranty and Environmentally Responsible Design
Documentation & Downloads
Specifications
Features & Specifications
| Max Supported Video Resolution | HDMI: 1920 X 1080 (1080P) @ 60HZ |
|---|---|
| HDCP Specification | 1.3 |
| Driver Required | No |
| USB Power Delivery (PD) Charging Support | Yes |
| Full Duplex Support | Yes |
| Remote Wakeup Support | Yes |
| USB Power Delivery (PD) Charging Specification | 2.0 |
| HDMI Specification | 1.3 |
|---|---|
| USB Specification | USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps) |
| Recommended Category Cable | Cat5/Cat5e/Cat6 Cables |
| Auto MDIX Support | Yes |
| Suspend Mode Support | Yes |
| Technology | Cat5/5e; Cat6; USB 3.1 (Gen 1); HDMI; USB; PD Charging |
Battery
| Battery Charging (1.2 Port) | Yes |
|---|
Certifications
| Certifications | Tested to CE, FCC, RoHS, REACH |
|---|
Connections
| Ports | 4 |
|---|---|
| Side B - Connector 1 | HDMI (FEMALE) |
| Side B - Connector 3 | USB Type-C (FEMALE) |
| Connector Plating | Nickel |
| Side A - Connector 1 | USB C (MALE) |
|---|---|
| Side B - Connector 2 | USB 3.0 A (FEMALE) |
| Side B - Connector 4 | RJ45 (FEMALE) |
Physical
| Cable Jacket Rating | VW-1 |
|---|---|
| Material of Construction | PVC and ABS |
| Shipping Weight (lbs.) | 0.20 |
| Unit Packaging Type | Box |
| Color | Black |
|---|---|
| Shipping Dimensions (hwd / in.) | 0.90 x 3.90 x 5.50 |
| Unit Dimensions (hwd / in.) | 0.57 x 1.57 x 3.15 |
| Unit Weight (lbs.) | 0.09 |
Input
| Bus Powered | Yes |
|---|---|
| Product Length (cm.) | 15.24 |
| Product Length (m.) | 0.15 |
| Product Length (in.) | 6 |
|---|---|
| Product Length (ft.) | 0.5 |
Output
| Charging Ports / Amps | 1.5A; 3A |
|---|
| Charging Watts | 60 |
|---|
Communications
| Network Speed | 1Gbps |
|---|
| IEEE Standards Supported | 802.3; 802.3u; 802.3az; 802.3x |
|---|
Environmental
| Operating Temperature Range | 32 to 113 F (0 to 45 C) |
|---|---|
| BTUs | 9 BTU/Hr |
| Operating Humidity Range | 10% to 85% RH, Non-Condensing |
| Storage Temperature Range | 14 to 158 F (-10 to 70 C) |
|---|---|
| Power Consumption (Watts) | 2.6 |
| Storage Humidity Range | 5% to 90% RH, Non-Condensing |
Overview
| UPC Code | 037332209160 |
|---|
Warranty
| Product Warranty Period (Worldwide) | 3-year limited warranty |
|---|
