Square D 9070T250D19 Industrial Control Transformer, 250VA, 1 Phase, 208-480V Primary, 24V Secondary
- MPN: 9070T250D19
- UPC: 785901905899
- PPN: SCH-9070T250D19
CAD
$231.08
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Schneider Electric's industrial control transformer is designed to provide reliable voltage transformation in various industrial applications. With a primary voltage range of 208 to 480 volts and a secondary output of 24 volts, this 250VA unit ensures efficient energy conversion for your control circuits. Built with durable components, it meets the demanding needs of power distribution while enhancing the operational reliability of your systems, making it an essential component for any industrial setting.
Features
- Rated for 250 VA, this Type T transformer is specifically engineered to handle the high inrush currents typical of electromagnetic devices like contactors and relays. By maintaining high voltage stability during startup, it prevents "chatter" and ensures your automated systems fire reliably every time, reducing wear on sensitive components.
- The D19 suffix signifies a highly flexible multi-voltage primary (208/240/277/380/480V) and a 115/120V secondary. This versatility allows industrial engineers to standardize on a single part number for various international and domestic power feeds, significantly reducing inventory costs and simplifying field replacements across diverse machinery.
- The core and coils are vacuum-impregnated with a specialized epoxy resin, protecting the internal windings from moisture, dust, and caustic contaminants. This solid-state physical protection prevents short circuits caused by environmental debris and dampens audible hum and vibration, ensuring a long service life in harsh CNC or motor control centers.
- Featuring molded-in terminal barriers and integrated screw terminals, the 9070T250D19 provides a secure point of connection that minimizes the risk of accidental contact with live circuits. This design facilitates faster installation for panel builders and allows for easy integration of optional primary and secondary fuse blocks without requiring additional mounting footprints.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Mexico
Depth4.74 in
Complementary Attributes
- Rated Power In Va
- 350 VA UL250 VA CSA, 250 VA NOM160 VA CE
Important Information Attributes
- Certificate Agency
- UL listed file E61239, CSA file LR37055 guide 184-N-90
- Local Publishable Date
- 2026-06-30
- Stocking Flag
- N
- Device Type
- Transformer - dry
- Traceability
- No
- Weee Product Category
- 5
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- With Recycled Cardboard
- Yes
- Product Contributes To Saved And Avoided Emissions
- No
- Electrical Connection
- screw clamp terminals
- Insulation Temperature
- 130 °C
- Phase
- 1 phase
- Product Availability
- Stock - Normally stocked in distribution facility
- Range Of Product
- T
- Sustainable Packaging
- No
- Weee Label
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Width Nominal
- 4.5 in
- Package Weight(Lbs)
- 4.813 kg
- Warranty (In Months)
- 18
Local Data StatusPublishable
Return IndicatorY
Stock Policy2
ServiceabilityNo
Weee ScopeIn
Scope PerimeterAt least in Europe
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date1905
China Rohs In ScopeNo
Without Single Use PlasticNo
Product Kit IdentifierN
Energy Efficiency OptimizedFalse
Materialcopper: winding
Primary Voltage208/240/277/380/480 V 24 V
Product Or Component TypeIndustrial Control Transformer
ReturnabilityYes
Temperature Rise80 °C
Height Nominal3.84 in
Nbr. Of Units In Pkg.1
Take-backNo
Customs Code8504314065
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Recycled Metal Content At Cr Level
- 0 %
- Eu Rohs Directive
- Compliant By Exemption
- Packaging Made With Recycled Cardboard
- Yes
- Product Compatibility
- FSC23
Take BackNo
Mercury FreeYes
Nema Degree Of Protectionnot rated (open device)
Packaging Without Single Use PlasticNo
Reach RegulationReference contains Substances of Very High Concern above the threshold
General Attributes
- Phase
- 1 phase
- Range Of Product
- T
Product Or Component TypeIndustrial Control Transformer
ETIM
- ETIM 8
- EC002486
ETIM 9EC002486
Contractual Warranty Attributes
- Warranty Period
- 10 Years
Warranty10 Years
