Tripp Lite B098-016-V 16-Port Console Server, USB Ports (2) - 4G LTE, Dual GbE NIC, 16Gb Flash, SD Card, Wi-Fi, Desktop/1U Rack, TAA
Tripp Lite B098-016-V 16-Port Console Server, USB Ports (2) - 4G LTE, Dual GbE NIC, 16Gb Flash, SD Card, Wi-Fi, Desktop/1U Rack, TAA
- MPN: B098-016-V
- UPC: 037332218070
- PPN: TRP-B098-016-V
Spec sheet
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
Description
16-Port Console Server, USB Ports (2) - 4G LTE, Dual GbE NIC, 16Gb Flash, SD Card, Wi-Fi, Desktop/1U Rack, TAA
Features
- Manage routers, UPS systems and other serial-based equipment from anywhere 24/7
- Built-in 4G LTE cellular modem with dual SIM card slots for out-of-band remote access
- Dual Gigabit Ethernet ports for primary network connection and automatic failover
- Designed for standard Cat5e/6 patch cable when connecting to Cisco devices
- Included Wi-Fi feature supports either Client or Access Point (WAP) mode
- 2-year limited warranty
- Access All Your Serial and Network Devices from Anywhere in the World at Any Time
- Cellular Modem for Out-of-Band Access
- Simple and Flexible Accessibility
- Wi-Fi Diversity Antenna Included
- Router/Gateway
- The Utmost in Security to Keep Your Sensitive Data Private
- PowerMan PDU and UPS Support
- USB Console
- Compact Design for Convenient Mounting
- TAA-Compliant for GSA Schedule Purchases
Specifications
Remote Access
- Modem Port
- No
Features & Specifications
- Port Selection
- CLI; GUI
- Authentication Supported
- RADIUS; LDAP; TACACS
- Technology
- Serial (RS232)
Driver RequiredNo
Common Access Card (CAC) SupportNo
Connections
- Ports
- 16
- Side A - Connector 2
- RJ11 (FEMALE)
- Side A - Connector 4
- SD (FEMALE)
- Side B - Connector 2
- (2) RJ45 (FEMALE)
Side A - Connector 1RJ45 (FEMALE)
Side A - Connector 3(2) USB A (FEMALE)
Side B - Connector 1(16) RJ45 (FEMALE)
Side B - Connector 3(2) SFP (FEMALE)
Physical
- Color
- Black
- Rackmountable
- Yes
- Shipping Weight (lbs.)
- 10.40
- Unit Packaging Type
- Box
Material of ConstructionMetal
Shipping Dimensions (hwd / in.)3.30 x 16.10 x 19.20
Unit Dimensions (hwd / in.)17 x 10 x 1.75
Unit Weight (lbs.)10
User Interface, Alerts & Controls
- LED Indicators
- 10 LEDs for Power, Heartbeat-Firmware Running, Serial Connectivity, Cellular Connectivity, Network Ports, and Wifi
Input
- Voltage Compatibility (VAC)
- 100; 110; 120; 125; 127; 200; 208; 220; 230; 240
- Redundancy - Dual Power Inputs
- Yes
Power Input ReceptacleIEC-320-C14
Communications
- IP Remote Access
- Yes
- IEEE Standards Supported
- 802.3; 802.3ab; 802.3ad
Network Speed1Gbps
Environmental
- Operating Temperature Range
- 41 to 122 F (5 to 50 C)
- Relative Humidity
- 5% to 90% RH, Non-Condensing
- Power Consumption (Watts)
- 15
Storage Temperature Range-22 to 140 F (-30 to 60 C)
BTUs51.2 BTU/Hr
Overview
- UPC Code
- 037332218070
Multi-UserYes
Warranty
- Product Warranty Period (Worldwide)
- 2-year limited warranty
