Tripp Lite B098-048 48-Port Console Server, USB Ports (2) - Dual GbE NIC, 16 Gb Flash, SD Card, Desktop/1U Rack, TAA
Tripp Lite B098-048 48-Port Console Server, USB Ports (2) - Dual GbE NIC, 16 Gb Flash, SD Card, Desktop/1U Rack, TAA
- MPN: B098-048
- UPC: 037332218063
- PPN: TRP-B098-048
Spec sheet
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
Description
48-Port Console Server, USB Ports (2) - Dual GbE NIC, 16 Gb Flash, SD Card, Desktop/1U Rack, TAA
Features
- Manage routers, UPS systems and other serial-based equipment from anywhere 24/7
- Validated to meet FIPS 140-2 standards to ensure utmost protection of private data
- Dual Gigabit Ethernet ports for primary network connection and automatic failover
- Designed for standard Cat5e/6 patch cable when connecting to Cisco devices
- Included Wi-Fi feature supports either Client or Access Point (WAP) mode
- 4-year limited warranty
- Access All Your Serial and Network Devices from Anywhere in the World at Any Time
- Simple and Flexible Accessibility
- Connect the Built-In V.92 Modem for Out-of-Band (OOB) Access
- Wi-Fi Diversity Antenna Included
- Router/Gateway
- The Utmost in Security to Keep Your Sensitive Data Private
- PowerMan PDU and UPS Support
- USB Console
- Compact Design for Convenient Mounting
- TAA-Compliant for GSA Schedule Purchases
Specifications
Features & Specifications
- Port Selection
- CLI; GUI
- Driver Required
- No
- Common Access Card (CAC) Support
- No
USB SpecificationUSB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps)
Authentication SupportedRADIUS; LDAP; TACACS
TechnologySerial (RS232)
Connections
- Ports
- 48
- Side A - Connector 2
- RJ11 (FEMALE)
- Side A - Connector 4
- SD (FEMALE)
- Side B - Connector 2
- (2) SFP (FEMALE)
Side A - Connector 1(2) USB A (FEMALE)
Side A - Connector 3RJ45 (FEMALE)
Side B - Connector 1(48) RJ45 (FEMALE)
Side B - Connector 3(2) RJ45 (FEMALE)
Physical
- Color
- Black
- Rackmountable
- Yes
- Shipping Weight (lbs.)
- 10.40
- Unit Packaging Type
- Box
Material of ConstructionMetal
Shipping Dimensions (hwd / in.)3.30 x 16.10 x 19.30
Unit Dimensions (hwd / in.)17 x 10 x 1.75
Unit Weight (lbs.)10
User Interface, Alerts & Controls
- LED Indicators
- 9 LED's for Power, Heartbeat-Firmware Running, Serial Connectivity, Network Ports and Wifi
Input
- Voltage Compatibility (VAC)
- 100; 110; 120; 125; 127; 200; 208; 220; 230; 240
- Redundancy - Dual Power Inputs
- Yes
Power Input ReceptacleIEC-320-C14
Communications
- IP Remote Access
- Yes
- IEEE Standards Supported
- 802.3; 802.3ab; 802.3ad
Network Speed1Gbps
Environmental
- Operating Temperature Range
- 41 to 122 F (5 to 50 C)
- Relative Humidity
- 5% to 90% RH, Non-Condensing
- Power Consumption (Watts)
- 15
Storage Temperature Range-22 to 140 F (-30 to 60 C)
BTUs51.2 BTU/Hr
Overview
- UPC Code
- 037332218063
Multi-UserYes
Warranty
- Product Warranty Period (Worldwide)
- 4-year limited warranty
