nVent Hoffman A10106CH Continuous Hinge Enclosure Clamp 10x10x6 Inch, Gray Mild Steel, NEMA Type 12
- MPN: A10106CH
- UPC: 783510548803
- PPN: HOF-A10106CH
- UNSPSC: 39121303
CAD
$219.69
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Type 12 Junction Boxes with easy access are ideal for housing and protecting electrical connections. This Continuous Hinge Enclosure Clamps CH Type 12, A10106CH item measures 10x10x6 inches with a material of Steel colored Gray.
Features
- Seams continuously welded and ground smooth
- Continuous hinge
- Screw-down door clamps
- Bonding provision on door
- External wall-mounting brackets for easy installation
- Oil-resistant gasket
- Weldnuts provided for mounting optional panels and terminal block kits in size 6.00 x 4.00 in. (152 x 102 mm) and larger
Documentation & Downloads
Specifications
Additional
- Protection Rating
- NEMA Type 12, Indoor, dust-resistant
- Weight
- 10.6 lb
- Width
- 10.0 in
- Depth
- 6.0 in
- Mounting
- 273 x 203 mm
- Finish
- Gray polyester powder coat, ANSI 61
- NEMA Rating
- 12
IP RatingIP65
Size10.00 x 10.00 x 6.00 in
Height10.0 in
Thickness1.9 mm
MaterialSteel, 14 gauge mild steel
ColorGray
