Schneider Electric NSYTBS342912 Thalassa Industrial ABS Enclosure IP66 341mm Height, Wall Mounted

MPN: NSYTBS342912
PPN: SCH-NSYTBS342912
UNSPSC: 39121303

$38.83

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Constructed from robust ABS material, this enclosure is designed to withstand challenging industrial environments while offering exceptional protection with an IP66 rating. The wall-mounted Thalassa enclosure from Schneider Electric ensures reliable safeguarding for your electrical components, making it suitable for various applications. With a height of 341mm, it provides ample space for effective organization and installation of critical equipment. Ideal for enhancing operational safety, this enclosure is a smart choice for those requiring durable and efficient protection solutions.

Features

Total electrical insulation (Class II) to avoid electric risks
High protection against dust and water (IP66)
Hard impact resistance (IK07)
Reinforced edges of the cover to ensure its robustness and perfect support during customization operations
Easy to use : only a flat-bladed screwdriver is required
Easy to install : 3 methods of fixing the box to its support
Smart design : fixing studs on the cover
Long life lasting without maintenance

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Hungary
Depth	128 mm

Weight	1000 g

Physical Attributes

Color	Gray RAL 7035)
Internal Height	325 mm

Internal Depth	120 mm
Internal Width	275 mm

Important Information Attributes

Persona Type Ids	LC, OM, OM8, PB, SI
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Device Composition	1 body, 1 cover4 cover screw
Carbon Footprint Of The End Of Life Phase C1 To C4	2 kg CO2 eq., 1.9921787918037264
Carbon Footprint Of The Manufacturing Phase A1 To A3	4 kg CO2 eq., 3.663079501032095
Local Data Status	Publishable
Return Indicator	Y
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	No
Tier Id	2
Function Option Id	STANDARD
Product Kit Identifier	N
Body Type	one piece moulded
Device Application	multi-purpose
Enclosure Mounting	wall mounted
Fire Resistance	650 °C IEC 60695-2-11
Material	ABS with 45% of post-industrial recycled content
Product Or Component Type	industrial box
Removable Parts	cover by captive screws
Software Version	v6.1
Total Lifecycle Carbon Footprint	8 kg CO2 eq.
Database Version	2023-02
Height Nominal	341 mm
Certificate Agency	TÜV
Customs Code	3925900000
Warranty In Months	18
Functional Unit Quantity	1
Reference Lifetime In Y	20

Persona Type Names	Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market Segmentation	Commercial, Industrial
Carbon Footprint Of The Distribution Phase A4	1.9853226836134066, 2 kg CO2 eq.
Carbon Footprint Of The Installation Phase A5	0.23381033071165908, 0.2 kg CO2 eq.
Carbon Footprint Of The Use Phase B2 B3 B4 B6	kg CO2 eq., 0
Local Publishable Date	2026-08-12
Weee Scope	Out
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1904
China Rohs In Scope	No
With Recycled Cardboard	No
Product Contributes To Saved And Avoided Emissions	No
Tier	2
Function Option	Standard
Average Percentage Of Recycled Plastic Content	45 %
Cover Fixing	plastic screws
Electrical Insulation Class	class II
Energy Efficiency Optimized	False
Lock Type	captive screw flat outside sealed area
Product Availability	Stock - Normally stocked in distribution facility
Range	PanelSeT
Returnability	Yes
Sustainable Packaging	No
Type Of Front Cover	low plain cover
Data Source	extrapolated product
Width Nominal	291 mm
Nbr. Of Units In Pkg.	1
Silicone Free	Yes
Functional Unit Description	Protect people from direct contact with live active parts and ensure the grouping of control, command and protection devices in a single enclosure or cabinet having the following dimensions H x L x D or an assembly of X enclosures or cabinets having the following dimensions H x L x D, with rated current In, while protecting them against mechanical impacts (IK) and the penetration of solid objects and liquids (IP), according to the appropriate use scenario, and for the reference service life of the product of 20 years.
Functional Unit Unit	Unit
Recyclability Potential In %	1

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Ambient Air Temperature For Storage	-15-40 °C, -15-40 °C
Reach Free Shvc	Yes
Toxic Heavy Metal Free	Yes
Silicon Free	Yes
Environmental Disclosure	ENVPEP2312020EN
Ip Degree Of Protection	IP66 conforming to NEMA 4.4X
Packaging Without Single Use Plastic	No
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2024-07-01
Psr Version	PSR-0005-ed3.1-EN-2023 12 08

Ambient Air Temperature For Operation	-25-60 °C, -25-60 °C
Take Back	No
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Carbon Footprint	7.874391307160887
Eu Rohs Directive	Compliant
Packaging Made With Recycled Cardboard	No
Reach Free Of Svhc	Yes
Pep Code	ENVPEP2312020EN
Pcr Version	PCR-4-ed4-EN-2021 09 06
Type Of Verification For The Pep	Independent external review
