Burndy

Burndy YNA32R15 Al Tube Compression Terminal, 15 Deg Bent, 2 Holes, 300 - 336.4 Kcmil ACSR, 336.4 - 350 Kcml Al, 395.1 - 395.2 Kcmil ACAR, 230 kV, 1.75" Spacing

Al Tube Compression Terminal, 15 Deg Bent, 2 Holes, 300 - 336.4 Kcmil ACSR, 336.4 - 350 Kcml Al, 395.1 - 395.2 Kcmil ACAR, 230 kV, 1.75" Spacing
  • MPN: YNA32R15
  • UPC: 781810016329
  • PPN: BUR-195208
  • UNSPSC: 39121405

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$360.51/ EA

Description

Al Tube Compression Terminal, 15 Deg Bent, 2 Holes, 300 - 336.4 Kcmil ACSR, 336.4 - 350 Kcml Al, 395.1 - 395.2 Kcmil ACAR, 230 kV, 1.75" Spacing.

Features

  • ACSR Compression Terminal, 15 Degree Bend
  • 2-Hole Pad

Specifications

Specifications

Country of Origin
United States
Conductor - ACAR Str Size Range
395.1-395.2
Conductor - ACSR Str Size Range
336.4 (26/7) Linnet kcmil-336.4 (30/7) Oriole kcmil
Dimension - L Length Overall mm
233 mm
Dimension - Length Side A inch
8.92 in
Dimension - Outside Diameter inch
1.19 in
Feature - Barrel Style
Tapered
Physical Attribute - Number of Holes
2
Plated
N
Prefilled Oxide Inhibitor
Y
Standards - RoHS Compliance Status
CM
Connector Type
Terminal
Class Code
B22
Harmonization Code
8535908020
Lead Time
12 wk
Die Index
717
Material
Aluminum
BOX SIZE
4.875x9.313x6.443 (in)
Carton - Number of Sub Packs
10
Carton - SCC-14 Next Lower Level Sub Pack
00781810016329
Case - SCC-14 Next Lower Level Sub Pack
30781810016320
Package - Total Units
10 EA
Package Weight
0.000 lb.
Pallet Height
44.750 in
Pallet Weight
1509.000 lb.
Standard Package Quantity
10
Conductor - ACAR Str Size395.1-395.2
Conductor - ACSR Str Size336.4 (26/7) Linnet kcmil;336.4 (30/7) Oriole kcmil
Dimension - Bolt Hole Size inch0.50 in
Dimension - Length Overall inch9.16 in
Dimension - Length Side B inch8.96 in
Dimension - Pad Width inch1.68 in
Feature - Barrel TypeLong
Physical Attribute - Pad Orientation15 Degree
Plating TypeUnplated
Product TypeCompression
Trade NameHYLUG™
Certification AgencyProposition 65
Freight Class Code16027000
Image Actual Or RepresentativeA
Sub Class CodeB22B12F
UL ListedNo
Base Unit of MeasureEA
Carton - Gross Weight per Pack6.100 lb.
Carton - Pack DescriptionCarton
Carton - Total Units10
Package - GTIN - Package30781810016320
Package Quantity10 EA
Pallet - GTIN - Package70781810016328
Pallet Length48.000 in
Pallet Width40.000 in
NAICS Code3359319104

Certifications

CSA Approved
No
ETL
No
cULusNo
UL RecognizedNo
