Burndy

Burndy YA312LN Non-insulated; Tin Plated YA312LN

Non-insulated; Tin Plated YA312LN
  • MPN: YA312LN
  • UPC: 781810505076
  • PPN: HBL-YA312LN

Spec sheet

Available to Order

Company Stock:

0

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$10.77/ E

Description

Copper Compression Lug, 2 Hole w/ Inspection Window, 350 kcmil, 1/2" Stud, 1-3/4" Stud Hole Spacing, Short Barrel, Tin Plated.

Specifications

Dimensions

Dimension - B Length fraction
1-1/16 in
Dimension - Bolt Hole Size inch
0.52 in
Dimension - D inch
3.01 in
Dimension - L Length Overall mm
119 mm
Dimension - N inch
0.62 in
Dimension - Pad Width inch
1.29 in
Dimension - Stud Size inch
1/2
Physical Attribute - Tongue Angle
Straight
Dimension - B Length inch1.06 in
Dimension - Bolt Size fraction1/2
Dimension - Hole Size mm14 mm
Dimension - Length Overall inch4.70 in
Dimension - Outside Diameter inch0.88 in
Dimension - Strip Length inch1-1/8
Dimension - Z inch0.64 in

Certifications and Compliance

Certification - CSA Approved
Yes
Certification - UL Recognized
No
Standards - RoHS Compliance Status
CM
Certification - ETLNo
Certification - cULusNo
UL ListedYes

Conductor Related

Conductor - Copper DLO Size Range
N/A
Conductor - Copper Str Navy Size Range
350 (91) Navy
Conductor - Copper Str Size Range
350 kcmil
Conductor - Copper Str Navy Size350 (91) Navy
Conductor - Copper Str Size350 kcmil
Conductor - MaterialCopper

General

Application
For Code Conductor
Connector Type
Terminal
Feature - Barrel Style
Chamfered
Material
Copper
Physical Attribute - Tongue Type
Standard
Plating Type
Tin - Electro Plated
Trade Name
HYLUG™
UPC
781810505076
Color CodeRed
Die Index18;324
Feature - Barrel TypeStandard
Physical Attribute - Number of Holes2
PlatedY
Sub BrandHYLUG
TypeStandard Barrel, Tin Plated

Electrical Ratings

Rating - KVA
35 kV
Voltage - Maximum
35000
Rating - Minimum Voltage600

Logistics

Minimum Pack Quantity
1
