Blackburn AL 100 MMNTN 45 Aluminum Compression Lug 100 mm² 45 Degree Bend, Tin Plated
- MPN: AL 100 MMNTN 45
- UPC: 783786072484
- PPN: T-B-AL 100 MMNTN 45
- UNSPSC: 39121409
CAD
$78.95
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Tin Plated, Aluminum Compression Lug with 45 Degree Bend, 100 mm2 ACSR, Bolt Holes 9/16 inch Diameter, Two Hole NEMA Pad with 1-3/4 inch Center to Center Spacing. Length 6-3/8 inches before Bending, Bore 19/32 inch Diameter x 1-15/16 inch Deep. Pad 3 inch long x 1-15/64 inch wide x 19/64 inch thick. Oxide Inhibitor. Red Cap. Tin Plated Finish. Dies 324 (U29ART). Dual Rated for Aluminum and Copper Conductors
Specifications
Additional Information
- Application
- General Purpose Lugs for Aluminum and Copper Terminations
- Connection Type
- Compression
- Insulation Material
- None
- Product Type
- Compression Lug Two Hole - 45 Degree
- Special Functions
- Dual Rated for use with Aluminum and Copper Conductors. Prefilled with Oxide Inhibitor. Marked with Conductor Sizes and Die Reference. Meet or Exceed ANSI C119.4 Specifications.
- Surface Finishing
- Tin Plated
- Wire Size
- 100 mm²
Brand / LabelHomac
Effective Date20110511
Product NameELECTRICAL CONNECTOR,>1000V
SizeUnbent length 6.375 inches, Barrel 1.938 inch, Pad 3.719 inch x 1.237 inch wide x .297 inch thick
StandardsANSI C119.4
Temperature Range90 °C
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4543 >> Wire connectors
