Burndy

Burndy YA342LN Copper YA342LN

Copper YA342LN
  • MPN: YA342LN
  • UPC: 781810505953
  • PPN: HBL-YA342LN

Spec sheet

Available to Order

Company Stock:

0

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$9.23/ E

Description

Copper Compression Lug, 2 Hole w/ Inspection Window, 500 kcmil, 1/2" Stud, 1-3/4" Stud Hole Spacing, Short Barrel, Tin Plated.

Specifications

Dimensions

Bolt Size
1/2 in
Dimension - B Length inch
1.27 in
Dimension - Bolt Size fraction
1/2
Dimension - Hole Size mm
14 mm
Dimension - Length Overall inch
5.06 in
Dimension - Outside Diameter inch
1.06 in
Dimension - Strip Length inch
1-7/16
Dimension - Z inch
0.64 in
Outside Diameter
1.06 in
Dimension - B Length fraction1-1/4 in
Dimension - Bolt Hole Size inch0.52 in
Dimension - D inch3.02 in
Dimension - L Length Overall mm129 mm
Dimension - N inch0.63 in
Dimension - Pad Width inch1.55 in
Dimension - Stud Size inch1/2
Length5.06 in
Physical Attribute - Tongue AngleStraight

Certifications and Compliance

Certification - CSA Approved
Yes
Certification - UL Recognized
No
Standards - RoHS Compliance Status
CM
Certification - ETLNo
Certification - cULusNo
UL ListedYes

Conductor Related

Conductor - Copper DLO Size Range
N/A
Conductor - Copper Str Size Range
500 kcmil
Conductor - Copper Str Size500 kcmil
Conductor - MaterialCopper

General

Application
For Code Conductor
Connector Type
Terminal
Feature - Barrel Type
Standard
Physical Attribute - Number of Holes
2
Plated
Y
Sub Brand
HYLUG
Type
Standard Barrel, Tin Plated
Color CodeBrown
Die Index20;299
MaterialCopper
Physical Attribute - Tongue TypeStandard
Plating TypeTin - Electro Plated
Trade NameHYLUG™
UPC781810505953

Electrical Ratings

Rating - KVA
35 kV
Voltage - Maximum
35000
Rating - Minimum Voltage600

Logistics

Minimum Pack Quantity
1
